3.3 Power Supply
Installing and Removing the Power Supply
Installing the Power Supply Unit
e 3U8G Series can accommodate four AC or two DC power supplies in the bay at the
rear of the chassis. Each unit provides up to 1200 Watts (200V AC) or 1000 Watts (100V
AC) of power. ree power supplies are required for full load operation, with the fourth
power supply purely as a redundant, load-sharing backup. It can be removed without
aecting system operation.
1. Align the power supply unit with the power supply slot. Ensure that the LED appears
on the lower right when you are installing the power supply unit.
2. Carefully slide the PSU all the way into the power supply bay until it clicks into place.
1
2
Before replacing the power supply, power o the server, unplug the power cord, and discon-
nect all wiring from the power supply.
