ASRock 3U8G-C612/V [51/59] Installation of memory modules dimm
![ASRock 3U8G-C612/V [51/59] Installation of memory modules dimm](/views2/1694134/page51/bg33.png)
46 47
English
Installation of Memory Modules (DIMM)
e DIMM only ts in one correct orientation. It will cause permanent damage to the
motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.
For more information about DIMM installation, please refer to the User Manual that
comes with the serverboard you use.
1
2
3
