Daikin RXYQ16M7W1B [104/182] Capacity tables
![Daikin RXYQ44M7W1B [104/182] Capacity tables](/views2/1707499/page104/bg68.png)
18
3
• Systems • Outdoor Units
103
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-2 Heating capacity
3-2-6 16HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
50 200
-19.8 -20.0 21.8 12.6 21.7 12.9 21.7 13.3 21.7 13.4 21.7 13.6 21.6 13.9
-18.8 -19.0 22.8 12.9 22.8 13.2 22.8 13.5 22.7 13.7 22.7 13.8 21.8 13.3
-16.7 -17.0 25.0 13.4 24.9 13.7 24.9 14.0 24.2 13.5 23.4 13.0 21.8 12.0
-14.7 -15.0 27.1 13.8 26.6 13.7 25.0 12.7 24.2 12.3 23.4 11.8 21.8 10.9
-12.6 -13.0 28.2 13.4 26.6 12.5 25.0 11.6 24.2 11.2 23.4 10.8 21.8 9.97
-10.5 -11.0 28.2 12.3 26.6 11.5 25.0 10.7 24.2 10.3 23.4 9.96 21.8 9.21
-9.5-10.028.211.826.611.125.010.324.29.9623.49.6021.88.88
-8.5 -9.1 28.2 11.5 26.6 10.7 25.0 9.99 24.2 9.64 23.4 9.29 21.8 8.60
-7.0 -7.6 28.2 10.8 26.6 10.2 25.0 9.48 24.2 9.15 23.4 8.82 21.8 8.18
-5.0 -5.6 28.2 10.1 26.6 9.51 25.0 8.88 24.2 8.58 23.4 8.28 21.8 7.68
-3.0 -3.7 28.2 9.56 26.6 8.96 25.0 8.39 24.2 8.10 23.4 7.82 21.8 7.27
0.0 -0.728.28.7626.68.2325.07.7124.27.4623.47.2021.86.71
3.0 2.2 28.2 8.13 26.6 7.64 25.0 7.17 24.2 6.94 23.4 6.70 21.8 6.25
5.0 4.1 28.2 7.76 26.6 7.30 25.0 6.86 24.2 6.64 23.4 6.42 21.8 5.99
7.0 6.0 28.2 7.43 26.6 7.00 25.0 6.57 24.2 6.36 23.4 6.16 21.8 5.75
9.0 7.9 28.2 7.13 26.6 6.72 25.0 6.32 24.2 6.12 23.4 5.92 21.8 5.53
11.0 9.8 28.26.8526.66.4625.06.0824.25.8923.45.7121.85.34
13.0 11.8 28.2 6.59 26.6 6.22 25.0 5.86 24.2 5.68 23.4 5.50 21.8 5.15
15.0 13.7 28.2 6.36 26.6 6.01 25.0 5.66 24.2 5.49 23.4 5.32 21.8 4.98
NOTE
1 is shown as reference
When selecting the unit models, avoid the Outdoor air temperature range shown by .
