Daikin RXYQ16M7W1B [52/182] Capacity tables
![Daikin RXYQ16M7W1B [52/182] Capacity tables](/views2/1707499/page52/bg34.png)
18
3
• Systems • Outdoor Units
51
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-1 Cooling capacity
3-1-11 26HP
26HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
90 585 10 44.0 7.59 52.5 9.16 61.0 10.81 65.3 11.7 69.5 12.5 78.0 14.3 86.5 16.1
12 44.0 7.72 52.5 9.32 61.0 11.01 65.3 11.9 69.5 12.8 78.0 14.6 86.5 16.5
14 44.0 7.86 52.5 9.49 61.0 11.22 65.3 12.1 69.5 13.0 78.0 14.9 86.5 16.8
16 44.0 7.99 52.5 9.67 61.0 11.43 65.3 12.3 69.5 13.3 78.0 15.2 86.5 17.0
18 44.0 8.14 52.5 9.85 61.0 11.66 65.3 12.6 69.5 13.5 78.0 15.5 86.5 17.6
20 44.0 8.29 52.5 10.0 61.0 11.89 65.3 12.8 69.5 14.0 78.0 16.6 86.5 18.4
21 44.0 8.37 52.5 10.1 61.0 12.09 65.3 13.3 69.5 14.5 78.0 17.2 86.5 18.9
23 44.0 8.52 52.5 10.6 61.0 12.94 65.3 14.2 69.5 15.6 78.0 18.5 85.5 19.7
25 44.0 8.98 52.5 11.3 61.0 13.83 65.3 15.2 69.5 16.7 78.0 19.8 84.3 20.6
27 44.0 9.56 52.5 12.0 61.0 14.77 65.3 16.3 69.5 17.8 78.0 21.2 83.0 21.4
29 44.0 10.2 52.5 12.8 61.0 15.76 65.3 17.4 69.5 19.0 78.0 22.1 81.8 22.3
31 44.0 10.8 52.5 13.6 61.0 16.81 65.3 18.5 69.5 20.3 78.0 23.0 80.5 23.2
33 44.0 11.5 52.5 14.5 61.0 17.91 65.3 19.7 69.5 21.7 77.7 23.9 79.3 24.1
35 44.0 12.2 52.5 15.4 61.0 19.07 65.3 21.0 69.5 23.1 76.5 24.7 78.1 24.9
37 44.0 12.9 52.5 16.4 61.0 20.30 65.3 22.4 69.5 24.6 75.2 25.6 76.8 25.8
39 44.0 13.7 52.5 17.4 61.0 21.60 65.3 23.9 69.5 26.2 74.0 26.5 75.6 26.7
80 520 10 39.16.7446.78.0754.29.4858.010.261.811.069.312.576.914.1
12 39.16.8546.78.2154.29.6558.010.461.811.269.312.776.914.4
14 39.16.9646.78.3554.29.8358.010.661.811.469.313.076.914.6
16 39.1 7.08 46.7 8.50 54.2 10.01 58.0 10.8 61.8 11.6 69.3 13.2 76.9 14.9
18 39.1 7.20 46.7 8.66 54.2 10.21 58.0 11.0 61.8 11.8 69.3 13.5 76.9 15.2
20 39.1 7.33 46.7 8.82 54.2 10.40 58.0 11.2 61.8 12.1 69.3 14.0 76.9 16.3
21 39.1 7.40 46.7 8.91 54.2 10.51 58.0 11.3 61.8 12.3 69.3 14.5 76.9 16.9
23 39.1 7.53 46.7 9.08 54.2 11.02 58.0 12.1 61.8 13.2 69.3 15.5 76.9 18.1
25 39.1 7.78 46.7 9.66 54.2 11.76 58.0 12.9 61.8 14.1 69.3 16.6 76.9 19.4
27 39.1 8.27 46.7 10.3 54.2 12.55 58.0 13.8 61.8 15.0 69.3 17.8 76.9 20.7
29 39.1 8.79 46.7 11.0 54.2 13.38 58.0 14.7 61.8 16.0 69.3 19.0 76.9 22.1
31 39.1 9.34 46.7 11.7 54.2 14.25 58.0 15.6 61.8 17.1 69.3 20.2 76.9 23.0
33 39.1 9.91 46.7 12.4 54.2 15.17 58.0 16.7 61.8 18.2 69.3 21.6 76.9 23.9
35 39.1 10.5 46.7 13.2 54.2 16.13 58.0 17.7 61.8 19.4 69.3 23.0 76.3 24.7
37 39.1 11.1 46.7 14.0 54.2 17.16 58.0 18.9 61.8 20.7 69.3 24.5 75.0 25.6
39 39.1 11.8 46.7 14.8 54.2 18.24 58.0 20.1 61.8 22.0 69.3 26.1 73.8 26.5
70 455 10 34.35.9340.97.0347.58.2150.88.8254.09.4560.610.767.212.1
12 34.36.0240.97.1547.58.3550.88.9854.09.6260.610.967.212.3
14 34.36.1140.97.2747.58.5050.89.1454.09.7960.611.167.212.5
16 34.36.2140.97.3947.58.6550.89.3154.09.9860.611.467.212.8
18 34.36.3140.97.5247.58.8150.89.4854.010.260.611.667.213.0
20 34.36.4240.97.6647.58.9850.89.6654.010.460.611.867.213.4
21 34.36.4740.97.7347.59.0750.89.7654.010.560.612.067.213.9
23 34.36.5940.97.8747.59.2550.810.154.011.060.612.867.214.9
25 34.36.7040.98.1947.59.8750.810.854.011.760.613.767.215.9
27 34.3 7.09 40.9 8.71 47.5 10.51 50.8 11.5 54.0 12.5 60.6 14.7 67.2 17.0
29 34.3 7.52 40.9 9.26 47.5 11.19 50.8 12.2 54.0 13.3 60.6 15.6 67.2 18.1
31 34.3 7.97 40.9 9.84 47.5 11.91 50.8 13.0 54.0 14.2 60.6 16.7 67.2 19.4
33 34.3 8.45 40.9 10.4 47.5 12.66 50.8 13.8 54.0 15.1 60.6 17.8 67.2 20.6
35 34.3 8.95 40.9 11.1 47.5 13.45 50.8 14.7 54.0 16.1 60.6 18.9 67.2 22.0
37 34.3 9.47 40.9 11.8 47.5 14.28 50.8 15.6 54.0 17.1 60.6 20.1 67.2 23.4
39 34.3 10.0 40.9 12.5 47.5 15.17 50.8 16.6 54.0 18.2 60.6 21.4 67.2 25.0
60 390 10 29.45.1635.06.0540.77.0043.57.5046.38.0152.09.0657.610.1
12 29.45.2335.06.1440.77.1243.57.6246.38.1452.09.2257.610.3
14 29.45.3135.06.2440.77.2443.57.7646.38.2952.09.3857.610.5
16 29.45.3835.06.3440.77.3643.57.8946.38.4452.09.5657.610.7
18 29.45.4735.06.4540.77.4943.58.0346.38.5952.09.7457.610.9
20 29.45.5535.06.5640.77.6343.58.1846.38.7552.09.9357.611.1
21 29.45.6035.06.6140.77.6943.58.2646.38.8352.010.057.611.3
23 29.45.6935.06.7340.77.8443.58.4146.39.0052.010.457.612.0
25 29.45.7835.06.8540.78.1443.58.8446.39.5752.011.157.612.8
27 29.45.9935.07.2640.78.6643.59.4146.310.252.011.957.613.6
29 29.4 6.35 35.0 7.71 40.7 9.21 43.5 10 46.3 10.9 52.0 12.6 57.6 14.6
31 29.4 6.72 35.0 8.18 40.7 9.78 43.5 11 46.3 11.5 52.0 13.4 57.6 15.5
33 29.4 7.11 35.0 8.67 40.7 10.39 43.5 11 46.3 12.3 52.0 14.3 57.6 16.5
35 29.4 7.52 35.0 9.18 40.7 11.02 43.5 12 46.3 13.0 52.0 15.2 57.6 17.6
37 29.4 7.95 35.0 9.72 40.7 11.69 43.5 13 46.3 13.8 52.0 16.2 57.6 18.7
39 29.4 8.40 35.0 10.3 40.7 12.39 43.5 14 46.3 14.7 52.0 17.2 57.6 19.9
