Daikin RXYQ16M7W1B [166/182] Dimensions
![Daikin RXYQ16M7W1B [166/182] Dimensions](/views2/1707499/page166/bga6.png)
18
6
• Systems • Outdoor Units
165
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
6 Dimensions
6-3 Installation service space
RXYQ-M
3D040335A
1,500 mm
Front
Suction side
500 mm
h 1
h 2
For single unit installtion
Pattern 1
Pattern 2
300 or more
300 or more
300 or more
100 or more
500 or more
600 or more
500 or more
10 or more
10 or more 10 or more
10 or more 10 or more
20 or more
20 or more
10 or more 10 or more
20 or more 20 or more
10 or more
500 or more
Front
100 or more
50 or more50 or more
500 or more
300 or more
200 or more
Front
Front
Front
100 or more
500 or more
300 or more
400 or more400 or more
200 or more
Wall height unrestricted
Wall height unrestricted
Front
50 or more 50 or more100 or more 100 or more
Front
Front
Front
500 or more
500 or more
900 or more
10 or more 10 or more
20 or more
20 or more
10 or more
10 or more
Front
Front
500 or more
500 or more
600 or more
50 or more 50 or more
100 or more
100 or more
50 or more 50 or more
Unit: mm
Front
Front
500 or more
500 or more
50 or more 50 or more
100 or more
100 or more
50 or more 50 or more
Front
Front
Pattern 3
Pattern 1
Pattern 2
Pattern 3
Pattern 1
Pattern 2
For installtion in rows For centralised group layout
NOTES
1 Wall height in case of patterns 1 and 2:
Front: 1,500mm
Suction side: 500mm
Side: Height unrestricted
2 If the above wall heights are exceeded then h1/2 and h2/2 should be added to the front and suction side service
spaces respectively as shown in the figure on the right.
3 When installing the units the most appropriate pattern should be selected from those shown above in order to
obtain the best fit in the space available always bearing in mind the need to leave enough room for a person
to pass between units and wall and for the air to circulate freely. (If more units are to be installed than are
accounted for in the above patterns your layout should take account of the possibility of short circuits.)
4 The units should be installed to leave sufficient space at the front for the on site refrigerant piping work to be
carried out comfortably.
