Daikin RXYQ16M7W1B [132/182] Capacity tables
![Daikin RXYQ5M7W1B [132/182] Capacity tables](/views2/1707499/page132/bg84.png)
18
3
• Systems • Outdoor Units
131
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-2 Heating capacity
3-2-16 36HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
130 1,170
-19.8 -20.0 61.4 14.0 61.2 15.7 60.9 17.5 60.8 18.3 60.6 19.2 60.4 20.9
-18.8 -19.0 63.6 15.1 63.3 16.8 63.1 18.4 62.9 19.3 62.8 20.1 62.5 21.8
-16.7 -17.0 67.9 17.1 67.6 18.6 67.4 20.2 67.2 21.0 67.1 21.7 66.8 23.3
-14.7 -15.0 72.2 18.8 71.9 20.3 71.7 21.7 71.5 22.5 71.4 23.2 71.1 24.6
-12.6 -13.0 76.5 20.4 76.2 21.7 76.0 23.1 75.8 23.8 75.7 24.4 75.4 25.8
-10.5 -11.0 80.8 21.7 80.5 23.0 80.3 24.3 80.1 24.9 80.0 25.6 79.8 26.9
-9.5-10.082.922.382.723.682.424.882.325.582.226.181.927.3
-8.5 -9.1 84.9 22.9 84.6 24.1 84.4 25.3 84.2 25.9 84.1 26.5 83.8 27.8
-7.0 -7.6 88.1 23.7 87.8 24.9 87.6 26.0 87.5 26.6 87.3 27.2 87.1 28.4
-5.0 -5.6 92.4 24.7 92.1 25.8 91.9 27.0 91.8 27.5 91.6 28.1 91.4 29.2
-3.0 -3.7 96.5 25.6 96.2 26.7 96.0 27.7 95.8 28.3 95.7 28.8 95.5 29.9
0.0 -0.7 103 26.8 103 27.8 102 28.8 102 29.3 102 29.8 102 30.8
3.0 2.2 109 27.9 109 28.8 109 29.8 109 30.2 108 30.7 108 31.6
5.0 4.1 113 28.5 113 29.4 113 30.3 113 30.8 112 31.2 112 32.1
7.0 6.0 117 29.1 117 30.0 117 30.8 117 31.3 117 31.7 116 32.6
9.0 7.9 121 29.6 121 30.5 121 31.3 121 31.7 121 32.2 120 33.0
11.0 9.8 126 30.1 125 31.0 125 31.8 125 32.2 125 32.6 125 33.4
13.0 11.8 130 30.6 130 31.4 129 32.2 129 32.6 129 33.0 128 33.5
15.0 13.7 134 31.1 134 31.8 133 32.6 133 33.0 133 33.4 128 32.2
120 1,080
-19.8 -20.0 61.1 16.3 60.8 17.9 60.6 19.5 60.5 20.3 60.4 21.1 60.1 22.7
-18.8 -19.0 63.2 17.4 63.0 18.9 62.7 20.4 62.6 21.2 62.5 22.0 62.3 23.5
-16.7 -17.0 67.5 19.2 67.3 20.6 67.0 22.0 66.9 22.8 66.8 23.5 66.6 24.9
-14.7 -15.0 71.8 20.8 71.6 22.1 71.4 23.5 71.2 24.1 71.1 24.8 70.9 26.1
-12.6 -13.0 76.1 22.2 75.9 23.5 75.7 24.7 75.5 25.3 75.4 26.0 75.2 27.2
-10.5 -11.0 80.4 23.5 80.2 24.6 80.0 25.8 79.8 26.4 79.7 27.0 79.5 28.2
-9.5-10.082.624.082.325.282.126.382.026.981.927.581.628.6
-8.5 -9.1 84.5 24.5 84.3 25.6 84.0 26.8 83.9 27.3 83.8 27.9 83.6 29.0
-7.0 -7.6 87.8 25.3 87.5 26.4 87.3 27.5 87.2 28.0 87.0 28.5 86.8 29.6
-5.0 -5.6 92.1 26.2 91.8 27.3 91.6 28.3 91.5 28.8 91.3 29.3 91.1 30.3
-3.0 -3.7 96.1 27.0 95.9 28.0 95.7 29.0 95.5 29.5 95.4 30.0 95.2 31.0
0.0 -0.7 103 28.2 102 29.1 102 30.0 102 30.5 102 30.9 102 31.9
3.0 2.2 109 29.2 109 30.0 108 30.9 108 31.3 108 31.8 108 32.6
5.0 4.1 113 29.7 113 30.6 112 31.4 112 31.8 112 32.2 112 33.1
7.0 6.0 117 30.3 117 31.1 117 31.9 116 32.3 116 32.7 116 33.5
9.0 7.9 121 30.8 121 31.6 121 32.3 121 32.7 120 33.1 118 33.0
11.0 9.8 125 31.2 125 32.0 125 32.7 125 33.1 124 33.5 118 31.7
13.0 11.8 129 31.7 129 32.4 129 33.2 129 33.5 127 33.1 118 30.4
15.0 13.7 134 32.1 133 32.8 133 33.5 131 33.2 127 31.9 118 29.3
110 990
-19.8 -20.0 60.7 18.7 60.5 20.1 60.3 21.6 60.2 22.3 60.1 23.0 59.8 24.5
-18.8 -19.0 62.9 19.6 62.7 21.0 62.4 22.4 62.3 23.1 62.2 23.8 62.0 25.2
-16.7 -17.0 67.2 21.3 67.0 22.6 66.7 23.9 66.6 24.6 66.5 25.2 66.3 26.5
-14.7 -15.0 71.5 22.7 71.3 24.0 71.0 25.2 70.9 25.8 70.8 26.4 70.6 27.7
-12.6 -13.0 75.8 24.0 75.6 25.2 75.3 26.3 75.2 26.9 75.1 27.5 74.9 28.7
-10.5 -11.0 80.1 25.2 79.9 26.3 79.6 27.4 79.5 27.9 79.4 28.5 79.2 29.5
-9.5-10.082.225.782.026.881.827.881.728.481.628.981.430.0
-8.5 -9.1 84.2 26.2 84.0 27.2 83.7 28.2 83.6 28.8 83.5 29.3 83.3 30.3
-7.0 -7.6 87.4 26.9 87.2 27.9 87.0 28.9 86.9 29.4 86.7 29.9 86.5 30.8
-5.0 -5.6 91.7 27.7 91.5 28.7 91.3 29.6 91.2 30.1 91.0 30.6 90.8 31.5
-3.0 -3.7 95.8 28.5 95.6 29.4 95.4 30.3 95.2 30.7 95.1 31.2 94.9 32.1
0.0 -0.7 102 29.5 102 30.4 102 31.2 102 31.6 102 32.1 101 32.9
3.0 2.2 108 30.4 108 31.2 108 32.0 108 32.4 108 32.8 108 33.6
5.0 4.1 113 31.0 112 31.7 112 32.5 112 32.9 112 33.2 108 32.4
7.0 6.0 117 31.5 116 32.2 116 32.9 116 33.3 116 33.7 108 31.0
9.0 7.9 121 31.9 121 32.6 120 33.3 120 33.7 116 32.4 108 29.8
11.0 9.8 125 32.3 125 33.0 124 33.7 120 32.4 116 31.1 108 28.6
13.0 11.8 129 32.8 129 33.4 124 32.3 120 31.1 116 29.9 108 27.5
15.0 13.7 133 33.1 132 33.5 124 31.1 120 29.9 116 28.8 108 26.5
100 900
-19.8 -20.0 60.4 21.0 60.2 22.3 60.0 23.6 59.9 24.3 59.8 25.0 59.6 26.3
-18.8 -19.0 62.5 21.8 62.3 23.1 62.1 24.4 62.0 25.0 61.9 25.7 61.7 26.9
-16.7 -17.0 66.8 23.4 66.6 24.6 66.4 25.7 66.3 26.3 66.2 26.9 66.0 28.1
-14.7 -15.0 71.1 24.7 70.9 25.8 70.7 26.9 70.6 27.5 70.5 28.0 70.3 29.2
-12.6 -13.0 75.4 25.9 75.2 26.9 75.0 28.0 74.9 28.5 74.8 29.0 74.6 30.1
-10.5 -11.0 79.7 26.9 79.5 27.9 79.3 28.9 79.2 29.4 79.1 29.9 78.9 30.9
-9.5-10.081.927.481.728.481.529.381.429.881.330.381.131.3
-8.5 -9.1 83.8 27.8 83.6 28.8 83.4 29.7 83.3 30.2 83.2 30.6 83.0 31.6
-7.0 -7.6 87.1 28.5 86.9 29.4 86.7 30.3 86.6 30.7 86.5 31.2 86.3 32.1
-5.0 -5.6 91.4 29.2 91.2 30.1 91.0 31.0 90.9 31.4 90.8 31.8 90.6 32.7
-3.0 -3.7 95.4 29.9 95.2 30.7 95.0 31.6 94.9 32.0 94.8 32.4 94.6 33.2
0.0 -0.7 102 30.9 102 31.6 102 32.4 101 32.8 101 33.2 98.5 32.6
3.0 2.2 108 31.7 108 32.4 108 33.1 108 33.5 106 33.0 98.5 30.3
5.0 4.1 112 32.2 112 32.9 112 33.6 109 32.8 106 31.5 98.5 29.0
7.0 6.0 116 32.6 116 33.3
113 32.6 109 31.4 106 30.2 98.5 27.8
9.0 7.9 120 33.0 120 33.7 113 31.3 109 30.1 106 29.0 98.5 26.7
11.0 9.8 124 33.4 120 32.4 113 30.1 109 28.9 106 27.8 98.5 25.7
13.0 11.8 128 33.3 120 31.1 113 28.9 109 27.8 106 26.7 98.5 24.7
15.0 13.7 128 32.1 120 29.9 113 27.8 109 26.8 106 25.8 98.5 23.8
