Daikin RXYQ16M7W1B [81/182] Capacity tables
![Daikin RXYQ16M7W1B [81/182] Capacity tables](/views2/1707499/page81/bg51.png)
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
3
• Systems • Outdoor Units
80
3 Capacity tables
3-1 Cooling capacity
3-1-21 46HP
46HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
130 1,495 10 113 20.9 135 25.6 157 30.5 168 31.1 171 30.5 175 29.2 179 27.9
12 113 21.3 135 26.1 157 31.0 167 30.9 169 30.3 173 29.0 177 28.5
14 113 21.7 135 26.6 157 31.4 165 30.8 167 30.1 171 29.9 175 30.2
16 113 22.1 135 27.1 157 31.3 162 31.1 164 31.2 169 31.5 173 31.8
18 113 22.6 135 27.7 157 32.5 160 32.6 162 32.8 166 33.1 170 33.4
20 113 23.0 135 29.5 156 34.1 158 34.2 160 34.4 164 34.7 168 35.1
21 113 23.7 135 30.5 155 34.9 157 35.0 159 35.2 163 35.6 167 35.9
23 113 25.3 135 32.7 153 36.4 155 36.6 157 36.8 161 37.2 165 37.6
25 113 27.1 135 35.0 150 38.0 153 38.2 155 38.4 159 38.8 163 39.2
27 113 28.9 135 37.5 148 39.6 150 39.8 152 40.1 156 40.5 161 40.9
29 113 30.9 135 40.0 146 41.2 148 41.5 150 41.7 154 42.1 158 42.6
31 113 32.9 135 42.4 144 42.9 146 43.1 148 43.3 152 43.8 156 44.3
33 113 35.1 135 44.0 142 44.5 144 44.7 146 45.0 150 45.5 154 46.0
35 113 37.4 135 45.6 139 46.1 141 46.4 144 46.6 148 47.1 152 47.7
37 113 39.8 133 47.2 137 47.7 138 48.0 139 48.3 142 48.8 145 49.4
39 113 42.4 126 48.8 129 49.4 131 49.7 132 50.0 135 50.5 137 51.1
120 1,380 10 104 19.1 125 23.4 145 27.8 155 30.0 165 31.3 172 30.1 176 28.9
12 104 19.5 125 23.8 145 28.3 155 30.6 165 31.1 170 29.9 174 28.7
14 104 19.8 125 24.2 145 28.8 155 31.2 164 31.0 168 29.7 172 29.9
16 104 20.2 125 24.7 145 29.4 155 31.4 162 31.0 166 31.3 169 31.6
18 104 20.6 125 25.2 145 30.4 155 32.4 160 32.6 163 32.9 167 33.2
20 104 21.0 125 26.2 145 32.7 155 34.0 157 34.2 161 34.5 165 34.8
21 104 21.2 125 27.1 145 33.9 154 34.8 156 35.0 160 35.3 164 35.6
23 104 22.7 125 29.1 145 36.2 152 36.4 154 36.6 158 36.9 162 37.3
25 104 24.2 125 31.1 145 37.8 150 38.0 152 38.2 156 38.5 160 38.9
27 104 25.8 125 33.3 145 39.4 148 39.6 150 39.8 154 40.2 157 40.6
29 104 27.6 125 35.5 144 41.0 146 41.2 148 41.4 151 41.8 155 42.2
31 104 29.4 125 37.9 142 42.6 143 42.8 145 43.0 149 43.5 153 43.9
33 104 31.3 125 40.4 139 44.2 141 44.4 143 44.7 147 45.1 151 45.6
35 104 33.3 125 43.1 137 45.8 139 46.1 141 46.3 145 46.8 148 47.3
37 104 35.4 125 46.0 135 47.4 137 47.7 139 47.9 141 48.5 144 49.0
39 104 37.7 124 48.5 128 49.1 130 49.3 131 49.6 134 50.1 137 50.7
110 1,265 10 95.8 17.4 114 21.1 133 25.1 142 27.1 151 29.2 169 31.0 173 29.9
12 95.8 17.7 114 21.5 133 25.6 142 27.6 151 29.7 167 30.8 171 29.7
14 95.8 18.0 114 21.9 133 26.1 142 28.2 151 30.3 165 30.7 168 29.7
16 95.8 18.3 114 22.4 133 26.6 142 28.7 151 30.9 163 31.1 166 31.3
18 95.8 18.7 114 22.8 133 27.1 142 29.5 151 32.4 161 32.7 164 32.9
20 95.8 19.0 114 23.3 133 28.7 142 31.7 151 34.0 158 34.3 162 34.5
21 95.8 19.2 114 24.0 133 29.7 142 32.9 151 34.8 157 35.1 161 35.4
23 95.8 20.1 114 25.7 133 31.9 142 35.3 151 36.3 155 36.7 159 37.0
25 95.8 21.5 114 27.4 133 34.1 142 37.8 149 37.9 153 38.3 156 38.6
27 95.8 22.9 114 29.3 133 36.5 142 39.3 147 39.5 151 39.9 154 40.2
29 95.8 24.4 114 31.3 133 39.0 142 40.9 145 41.1 148 41.5 152 41.9
31 95.8 26.0 114 33.4 133 41.7 141 42.5 143 42.7 146 43.1 150 43.5
33 95.8 27.7 114 35.6 133 43.9 139 44.1 141 44.3 144 44.8 147 45.2
35 95.8 29.5 114 37.9 133 45.5 137 45.7 138 46.0 142 46.4 145 46.9
37 95.8 31.3 114 40.4 133 47.1 134 47.4 136 47.6 140 48.1 143 48.5
39 95.8 33.3 114 43.0 128 48.7 129 49.0 130 49.2 133 49.7 136 50.2
100 1,150 10 87.1 15.7 104 19.0 121 22.5 129 24.3 137 26.1 154 29.9 170 30.9
12 87.1 15.9 104 19.3 121 22.9 129 24.8 137 26.6 154 30.4 167 30.8
14 87.1 16.2 104 19.7 121 23.4 129 25.2 137 27.1 154 31.0 165 30.6
16 87.1 16.5 104 20.1 121 23.8 129 25.7 137 27.7 154 31.4 163 31.1
18 87.1 16.8 104 20.5 121 24.3 129 26.2 137 28.2 154 32.4 161 32.7
20 87.1 17.1 104 20.9 121 25.0 129 27.6 137 30.2 154 34.0 159 34.3
21 87.1 17.3 104 21.1 121 25.9 129 28.5 137 31.3 154 34.8 158 35.1
23 87.1 17.8 104 22.5 121 27.7 129 30.6 137 33.6 152 36.4 155 36.7
25 87.1 18.9 104 24.0 121 29.7 129 32.7 137 36.0 150 38.0 153 38.3
27 87.1 20.2 104 25.6 121 31.7 129 35.0 137 38.5 148 39.6 151 39.9
29 87.1 21.5 104 27.3 121 33.9 129 37.4 137 40.8 146 41.2 149 41.5
31 87.1 22.9 104 29.1 121 36.1 129 39.9 137 42.4 143 42.8 146 43.2
33 87.1 24.3 104 31.0 121 38.5 129 42.6 137 44.0 141 44.4 144 44.8
35 87.1 25.9 104 33.0 121 41.1 129 45.5 136 45.6 139 46.0 142 46.4
37 87.1 27.5 104 35.1 121 43.8 129 47.0 134 47.3 137 47.7 140 48.1
39 87.1 29.2 104 37.4 121 46.6 128 48.6 130 48.9 132 49.3 135 49.8
