Daikin RXYQ16M7W1B [135/182] Capacity tables
![Daikin RXYQ16M7W1B [135/182] Capacity tables](/views2/1707499/page135/bg87.png)
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
3
• Systems • Outdoor Units
134
3 Capacity tables
3-2 Heating capacity
3-2-17 38HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
130 1,235
-19.8 -20.0 63.9 13.9 63.6 15.7 63.3 17.5 63.2 18.4 63.1 19.3 62.8 21.1
-18.8 -19.0 66.1 15.1 65.8 16.8 65.6 18.5 65.4 19.4 65.3 20.3 65.0 22.0
-16.7 -17.0 70.6 17.1 70.3 18.8 70.0 20.4 69.9 21.2 69.8 22.0 69.5 23.6
-14.7 -15.0 75.0 19.0 74.8 20.5 74.5 22.0 74.4 22.7 74.2 23.5 74.0 25.0
-12.6 -13.0 79.5 20.6 79.2 22.0 79.0 23.4 78.8 24.1 78.7 24.8 78.4 26.2
-10.5 -11.0 84.0 22.0 83.7 23.3 83.4 24.7 83.3 25.3 83.2 26.0 82.9 27.3
-9.5-10.086.222.685.923.985.725.285.525.985.426.585.127.8
-8.5 -9.1 88.2 23.2 88.0 24.5 87.7 25.7 87.5 26.4 87.4 27.0 87.1 28.3
-7.0 -7.6 91.6 24.0 91.3 25.3 91.0 26.5 90.9 27.1 90.8 27.7 90.5 29.0
-5.0 -5.6 96.1 25.1 95.8 26.3 95.5 27.4 95.4 28.0 95.2 28.6 95.0 29.8
-3.0 -3.7 100 26.0 100 27.1 99.8 28.3 99.6 28.8 99.5 29.4 99.2 30.5
0.0 -0.7 107 27.3 107 28.4 106 29.4 106 29.9 106 30.4 106 31.5
3.0 2.2 113 28.4 113 29.4 113 30.4 113 30.9 113 31.4 112 32.3
5.0 4.1 118 29.1 117 30.0 117 31.0 117 31.4 117 31.9 117 32.9
7.0 6.0 122 29.7 122 30.6 121 31.5 121 32.0 121 32.4 121 33.3
9.0 7.9 126 30.2 126 31.1 126 32.0 126 32.4 125 32.9 125 33.8
11.0 9.8 130 30.8 130 31.6 130 32.5 130 32.9 130 33.3 129 34.2
13.0 11.8 135 31.3 135 32.1 134 32.9 134 33.3 134 33.8 134 34.6
15.0 13.7 139 31.8 139 32.6 139 33.3 139 33.7 138 34.1 135 33.7
120 1,140
-19.8 -20.0 63.5 16.3 63.2 18.0 63.0 19.7 62.9 20.5 62.7 21.3 62.5 23.0
-18.8 -19.0 65.7 17.4 65.5 19.0 65.2 20.6 65.1 21.4 65.0 22.2 64.7 23.8
-16.7 -17.0 70.2 19.3 70.0 20.8 69.7 22.3 69.6 23.1 69.5 23.8 69.2 25.3
-14.7 -15.0 74.7 21.0 74.4 22.4 74.2 23.8 74.0 24.5 73.9 25.2 73.7 26.6
-12.6 -13.0 79.1 22.5 78.9 23.8 78.6 25.1 78.5 25.8 78.4 26.4 78.1 27.7
-10.5 -11.0 83.6 23.8 83.4 25.0 83.1 26.3 83.0 26.9 82.9 27.5 82.6 28.7
-9.5-10.085.924.485.625.685.326.885.227.485.128.084.829.2
-8.5 -9.1 87.9 24.9 87.6 26.1 87.4 27.3 87.2 27.8 87.1 28.4 86.9 29.6
-7.0 -7.6 91.2 25.7 91.0 26.8 90.7 28.0 90.6 28.5 90.5 29.1 90.2 30.2
-5.0 -5.6 95.7 26.7 95.4 27.8 95.2 28.8 95.1 29.4 94.9 29.9 94.7 31.0
-3.0 -3.7 99.9 27.5 99.7 28.6 99.4 29.6 99.3 30.1 99.2 30.6 98.9 31.6
0.0 -0.7 107 28.7 106 29.7 106 30.7 106 31.1 106 31.6 106 32.6
3.0 2.2 113 29.7 113 30.7 113 31.6 112 32.0 112 32.5 112 33.4
5.0 4.1 117 30.3 117 31.2 117 32.1 117 32.5 117 33.0 116 33.8
7.0 6.0 122 30.9 121 31.8 121 32.6 121 33.0 121 33.4 121 34.3
9.0 7.9 126 31.4 126 32.2 125 33.1 125 33.5 125 33.9 124 34.5
11.0 9.8 130 31.9 130 32.7 130 33.5 129 33.9 129 34.3 124 33.1
13.0 11.8 135 32.4 134 33.2 134 33.9 134 34.3 134 34.6 124 31.8
15.0 13.7 139 32.8 139 33.6 138 34.3 138 34.7 134 33.3 124 30.6
110 1,045
-19.8 -20.0 63.1 18.8 62.9 20.3 62.7 21.8 62.6 22.6 62.4 23.3 62.2 24.9
-18.8 -19.0 65.4 19.8 65.1 21.2 64.9 22.7 64.8 23.4 64.7 24.2 64.4 25.6
-16.7 -17.0 69.8 21.5 69.6 22.9 69.4 24.2 69.3 24.9 69.1 25.6 68.9 27.0
-14.7 -15.0 74.3 23.0 74.1 24.3 73.8 25.6 73.7 26.2 73.6 26.9 73.4 28.2
-12.6 -13.0 78.8 24.4 78.5 25.6 78.3 26.8 78.2 27.4 78.1 28.0 77.9 29.2
-10.5 -11.0 83.2 25.6 83.0 26.7 82.8 27.9 82.7 28.4 82.6 29.0 82.3 30.1
-9.5-10.085.526.285.327.385.028.484.928.984.829.584.630.6
-8.5 -9.1 87.5 26.6 87.3 27.7 87.0 28.8 86.9 29.3 86.8 29.9 86.6 30.9
-7.0 -7.6 90.8 27.4 90.6 28.4 90.4 29.4 90.3 30.0 90.2 30.5 89.9 31.5
-5.0 -5.6 95.3 28.3 95.1 29.2 94.9 30.2 94.7 30.7 94.6 31.2 94.4 32.2
-3.0 -3.7 99.6 29.0 99.3 30.0 99.1 30.9 99.0 31.4 98.9 31.9 98.6 32.8
0.0 -0.7 106 30.1 106 31.0 106 31.9 106 32.3 106 32.8 105 33.7
3.0 2.2 113 31.1 113 31.9 112 32.7 112 33.1 112 33.6 112 34.4
5.0 4.1 117 31.6 117 32.4 117 33.2 116 33.6 116 34.0 114 33.9
7.0 6.0 121 32.1 121 32.9 121 33.7 121 34.1 121 34.5 114 32.4
9.0 7.9 125 32.6 125 33.4 125 34.1 125 34.5 122 33.9 114 31.1
11.0 9.8 130 33.1 130 33.8 129 34.5 127 33.8 122 32.5 114 29.9
13.0 11.8 134 33.5 134 34.2 131 33.8 127 32.5 122 31.2 114 28.7
15.0 13.7 138 33.9 138 34.6 131 32.5 127 31.3 122 30.1 114 27.7
100 950
-19.8 -20.0 62.8 21.2 62.6 22.6 62.3 24.0 62.2 24.7 62.1 25.4 61.9 26.7
-18.8 -19.0 65.0 22.1 64.8 23.4 64.6 24.8 64.5 25.4 64.4 26.1 64.2 27.4
-16.7 -17.0 69.5 23.7 69.3 24.9 69.1 26.2 68.9 26.8 68.8 27.4 68.6 28.7
-14.7 -15.0 73.9 25.1 73.7 26.3 73.5 27.4 73.4 28.0 73.3 28.6 73.1 29.8
-12.6 -13.0 78.4 26.3 78.2 27.4 78.0 28.5 77.9 29.1 77.8 29.6 77.6 30.7
-10.5 -11.0 82.9 27.4 82.7 28.4 82.5 29.5 82.4 30.0 82.3 30.5 82.0 31.5
-9.5-10.085.127.984.928.984.729.984.630.484.530.984.331.9
-8.5 -9.1 87.1 28.3 86.9 29.3 86.7 30.3 86.6 30.8 86.5 31.3 86.3 32.3
-7.0 -7.6 90.5 29.0 90.3 30.0 90.1 30.9 90.0 31.4 89.9 31.8 89.6 32.8
-5.0 -5.6 94.9 29.8 94.7 30.7 94.5 31.6 94.4 32.1 94.3 32.5 94.1 33.4
-3.0 -3.7 99.2 30.5 99.0 31.4 98.8 32.3 98.7 32.7 98.6 33.1 98.4 34.0
0.0 -0.7 106 31.5 106 32.3 105 33.1 105 33.5 105 33.9 104 34.1
3.0 2.2 112 32.4 112 33.1 112 33.9 112 34.3 111 34.5 104 31.7
5.0 4.1 117 32.9 116 33.6 116 34.4 115 34.3 111 32.9 104 30.3
7.0 6.0 121 33.4 121 34.1
119 34.1 115 32.8 111 31.5 104 29.0
9.0 7.9 125 33.8 125 34.5 119 32.7 115 31.5 111 30.3 104 27.9
11.0 9.8 129 34.2 127 33.8 119 31.4 115 30.2 111 29.1 104 26.8
13.0 11.8 134 34.6 127 32.5 119 30.2 115 29.0 111 27.9 104 25.8
15.0 13.7 134 33.5 127 31.3 119 29.1 115 28.0 111 26.9 104 24.9
