Daikin RXYQ16M7W1B [148/182] Capacity tables
![Daikin RXYQ16M7W1B [148/182] Capacity tables](/views2/1707499/page148/bg94.png)
18
3
• Systems • Outdoor Units
147
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-2 Heating capacity
3-2-21 46HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
90 1,035
-19.8 -20.0 77.0 29.3 76.8 30.8 76.6 32.2 76.5 33.0 76.4 33.7 76.1 35.2
-18.8 -19.0 79.8 30.2 79.6 31.7 79.3 33.1 79.2 33.8 79.1 34.5 78.9 36.0
-16.7 -17.0 85.3 31.9 85.1 33.3 84.9 34.6 84.8 35.3 84.6 36.0 84.4 37.3
-14.7 -15.0 90.9 33.5 90.6 34.7 90.4 36.0 90.3 36.6 90.2 37.2 89.9 38.5
-12.6 -13.0 96.4 34.8 96.1 36.0 95.9 37.1 95.8 37.7 95.7 38.3 95.5 39.5
-10.5 -11.0 102 36.0 102 37.1 101 38.2 101 38.8 101 39.3 101 40.4
-9.5 -10.0 105 36.5 104 37.6 104 38.7 104 39.2 104 39.8 104 40.8
-8.5 -9.1 107 37.0 107 38.0 107 39.1 107 39.6 106 40.1 106 41.2
-7.0 -7.6 111 37.7 111 38.7 111 39.7 111 40.2 111 40.8 110 41.8
-5.0 -5.6 117 38.6 117 39.6 116 40.5 116 41.0 116 41.5 114 41.2
-3.0 -3.7 122 39.3 122 40.3 122 41.2 121 41.7 121 42.1 114 39.1
0.0 -0.7 130 40.4 130 41.3 130 42.2 126 40.8 122 39.2 114 36.1
3.0 2.2 138 41.4 138 42.2 131 39.5 126 38.0 122 36.5 114 33.6
5.0 4.1 144 41.9 139 40.6 131 37.7 126 36.3 122 34.9 114 32.2
7.0 6.0 147 41.7 139 38.9 131 36.2 126 34.8 122 33.5 114 30.9
9.0 7.9 147 40.0 139 37.3 131 34.7 126 33.4 122 32.2 114 29.7
11.0 9.8 147 38.4 139 35.8 131 33.4 126 32.1 122 30.9 114 28.6
13.0 11.8 147 36.9 139 34.4 131 32.1 126 30.9 122 29.8 114 27.5
15.0 13.7 147 35.5 139 33.2 131 30.9 126 29.8 122 28.7 114 26.6
80 920
-19.8 -20.0 76.6 32.2 76.4 33.5 76.2 34.8 76.1 35.5 76.0 36.2 75.8 37.5
-18.8 -19.0 79.4 33.0 79.2 34.3 79.0 35.6 78.8 36.2 78.7 36.9 78.5 38.1
-16.7 -17.0 84.9 34.6 84.7 35.8 84.5 37.0 84.4 37.5 84.3 38.1 84.1 39.3
-14.7 -15.0 90.4 35.9 90.2 37.0 90.0 38.1 89.9 38.7 89.8 39.3 89.6 40.4
-12.6 -13.0 95.9 37.1 95.7 38.1 95.5 39.2 95.4 39.7 95.3 40.2 95.1 41.3
-10.5 -11.0 101 38.1 101 39.1 101 40.1 101 40.6 101 41.1 101 42.1
-9.5 -10.0 104 38.6 104 39.6 104 40.6 104 41.0 104 41.5 101 41.0
-8.5 -9.1 107 39.0 106 40.0 106 40.9 106 41.4 106 41.9 101 39.8
-7.0 -7.6 111 39.7 111 40.6 110 41.5 110 41.9 109 41.4 101 38.0
-5.0 -5.6 116 40.5 116 41.3 116 42.2 112 40.6 109 39.0 101 35.9
-3.0 -3.7 122 41.2 121 42.0 116 40.0 112 38.5 109 37.0 101 34.1
0.0 -0.7 130 42.1 123 39.7 116 36.9 112 35.6 109 34.2 101 31.5
3.0 2.2 131 39.6 123 37.0 116 34.4 112 33.1 109 31.9 101 29.4
5.0 4.1 131 37.9 123 35.4 116 32.9 112 31.7 109 30.5 101 28.2
7.0 6.0 131 36.3 123 33.9 116 31.6 112 30.4 109 29.3 101 27.1
9.0 7.9 131 34.8 123 32.6 116 30.4 112 29.3 109 28.2 101 26.1
11.0 9.8 131 33.5 123 31.3 116 29.2 112 28.2 109 27.2 101 25.2
13.0 11.8 131 32.2 123 30.1 116 28.1 112 27.1 109 26.2 101 24.2
15.0 13.7 131 31.0 123 29.1 116 27.2 112 26.2 109 25.3 101 23.4
70 805
-19.8 -20.0 76.1 35.1 76.0 36.3 75.8 37.4 75.7 38.0 75.6 38.6 75.4 39.7
-18.8 -19.0 78.9 35.8 78.7 37.0 78.6 38.1 78.5 38.6 78.4 39.2 78.2 40.3
-16.7 -17.0 84.4 37.2 84.3 38.2 84.1 39.3 84.0 39.8 83.9 40.3 83.7 41.4
-14.7 -15.0 90.0 38.4 89.8 39.3 89.6 40.3 89.5 40.8 89.4 41.3 88.5 41.7
-12.6 -13.0 95.5 39.4 95.3 40.3 95.1 41.2 95.0 41.7 94.9 42.2 88.5 38.7
-10.5 -11.0 101 40.3 101 41.2 101 42.1 98.2 41.0 95.0 39.4 88.5 36.2
-9.5 -10.0 104 40.7 104 41.6 102 41.2 98.2 39.6 95.0 38.1 88.5 35.1
-8.5 -9.1 106 41.1 106 41.9 102 40.0 98.2 38.5 95.0 37.0 88.5 34.1
-7.0 -7.6 110 41.7 108 41.2 102 38.2 98.2 36.8 95.0 35.4 88.5 32.6
-5.0 -5.6 115 41.6 108 38.8 102 36.0 98.2 34.7 95.0 33.4 88.5 30.8
-3.0 -3.7 115 39.4 108 36.8 102 34.2 98.2 33.0 95.0 31.7 88.5 29.3
0.0 -0.7 115 36.4 108 34.0 102 31.7 98.2 30.5 95.0 29.4 88.5 27.2
3.0 2.2 115 33.9 108 31.7 102 29.6 98.2 28.5 95.0 27.5 88.5 25.4
5.0 4.1 115 32.5 108 30.4 102 28.4 98.2 27.4 95.0 26.4 88.5 24.4
7.0 6.0 115 31.1 108 29.2 102 27.2 98.2 26.3 95.0 25.3 88.5 23.5
9.0 7.9 115 29.9 108 28.0 102 26.2 98.2 25.3 95.0 24.4 88.5 22.7
11.0 9.8 115 28.8 108 27.0 102 25.3 98.2 24.4 95.0 23.5 88.5 21.9
13.0 11.8 115 27.7 108 26.0 102 24.3 98.2 23.5 95.0 22.7 88.5 21.1
15.0 13.7 115 26.8 108 25.1 102 23.5 98.2 22.8 95.0 22.0 88.5 20.4
60 690
-19.8 -20.0 75.7 38.0 75.5 39.0 75.4 40.0 75.3 40.5 75.2 41.0 75.1 42.0
-18.8 -19.0 78.5 38.6 78.3 39.6 78.2 40.6 78.1 41.1 78.0 41.5 75.8 40.8
-16.7 -17.0 84.0 39.8 83.8 40.7 83.7 41.6 83.6 42.0 81.4 40.8 75.8 37.5
-14.7 -15.0 89.5 40.8 89.4 41.7 87.0 40.9 84.2 39.3 81.4 37.8 75.8 34.8
-12.6 -13.0 95.0 41.7 92.6 40.9 87.0 38.0 84.2 36.6 81.4 35.2 75.8 32.4
-10.5 -11.0 98.2 40.9 92.6 38.2 87.0 35.5 84.2 34.2 81.4 32.9 75.8 30.4
-9.5-10.098.239.692.637.087.034.484.233.181.431.975.829.4
-8.5 -9.1 98.2 38.5 92.6 35.9 87.0 33.4 84.2 32.2 81.4 31.0 75.8 28.7
-7.0 -7.6 98.2 36.8 92.6 34.3 87.0 32.0 84.2 30.8 81.4 29.7 75.8 27.4
-5.0 -5.6 98.2 34.7 92.6 32.4 87.0 30.2 84.2 29.2 81.4 28.1 75.8 26.0
-3.0 -3.7 98.2 32.9 92.6 30.8 87.0 28.8 84.2 27.7 81.4 26.7 75.8 24.8
0.0 -0.798.230.592.628.687.026.784.225.881.424.975.823.1
3.0 2.2 98.2 28.5 92.6 26.7 87.0 25.0 84.2 24.1 81.4 23.3 75.8 21.6
5.0 4.1 98.2 27.3 92.6 25.7 87.0 24.0 84.2 23.2 81.4 22.4 75.8 20.8
7.0 6.0 98.2 26.3 92.6 24.7 87.0 23.1 84.2 22.3 81.4 21.6 75.8 20.1
9.0 7.9 98.2 25.3 92.6 23.8 87.0 22.3 84.2 21.5 81.4 20.8 75.8 19.4
11.0 9.8 98.224.492.622.987.021.584.220.881.420.175.818.7
13.0 11.8 98.2 23.5 92.6 22.1 87.0 20.7 84.2 20.1 81.4 19.4 75.8 18.1
15.0 13.7 98.2 22.7 92.6 21.4 87.0 20.1 84.2 19.4 81.4 18.8 75.8 17.5
