![Daikin RXYQ16M7W1B [72/182] Capacity tables](/img/pdf.png)
Daikin RXYQ16M7W1B [72/182] Capacity tables
![Daikin RXYQ16M7W1B [72/182] Capacity tables](/views2/1707499/page72/bg48.png)
18
3
• Systems • Outdoor Units
71
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-1 Cooling capacity
3-1-18 40HP
40HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
130 1,300 10 98.7 17.9 118 21.9 137 26.0 146 26.6 149 26.0 153 24.9 156 23.8
12 98.7 18.2 118 22.3 137 26.5 145 26.4 147 25.9 151 24.8 154 24.4
14 98.7 18.5 118 22.7 137 26.9 144 26.3 145 25.7 149 25.5 152 25.8
16 98.7 18.9 118 23.2 137 26.7 142 26.5 143 26.7 147 26.9 151 27.2
18 98.7 19.3 118 23.6 137 27.7 140 27.9 142 28.0 145 28.3 149 28.6
20 98.7 19.7 118 25.2 136 29.1 138 29.2 140 29.4 143 29.7 147 30.0
21 98.7 20.2 118 26.1 135 29.8 137 29.9 139 30.1 142 30.4 146 30.7
23 98.7 21.6 118 27.9 133 31.1 135 31.3 137 31.4 140 31.8 144 32.1
25 98.7 23.1 118 29.9 131 32.5 133 32.7 135 32.8 138 33.2 142 33.5
27 98.7 24.7 118 32.0 129 33.9 131 34.0 133 34.2 136 34.6 140 34.9
29 98.7 26.4 118 34.2 127 35.2 129 35.4 131 35.6 134 36.0 138 36.4
31 98.7 28.1 118 36.2 125 36.6 127 36.8 129 37.0 133 37.4 136 37.8
33 98.7 30.0 118 37.6 124 38.0 125 38.2 127 38.4 131 38.8 134 39.3
35 98.7 31.9 118 38.9 122 39.4 123 39.6 125 39.8 129 40.3 132 40.7
37 98.7 34.0 116 40.3 119 40.8 121 41.0 122 41.3 125 41.7 128 42.2
39 98.7 36.2 112 41.7 115 42.2 116 42.4 118 42.7 121 43.2 124 43.7
120 1,200 10 91.1 16.3 109 20.0 126 23.7 135 25.6 144 26.7 150 25.7 154 24.7
12 91.1 16.6 109 20.3 126 24.2 135 26.1 144 26.6 148 25.6 152 24.5
14 91.1 16.9 109 20.7 126 24.6 135 26.6 143 26.4 146 25.4 150 25.6
16 91.1 17.3 109 21.1 126 25.1 135 26.8 141 26.5 144 26.7 148 27.0
18 91.1 17.6 109 21.5 126 26.0 135 27.7 139 27.8 143 28.1 146 28.3
20 91.1 17.9 109 22.4 126 27.9 135 29.1 137 29.2 141 29.5 144 29.7
21 91.1 18.1 109 23.2 126 28.9 135 29.7 136 29.9 140 30.2 143 30.4
23 91.1 19.4 109 24.8 126 31.0 133 31.1 134 31.2 138 31.5 141 31.8
25 91.1 20.7 109 26.6 126 32.3 131 32.5 133 32.6 136 32.9 139 33.2
27 91.1 22.1 109 28.4 126 33.7 129 33.8 131 34.0 134 34.3 137 34.7
29 91.1 23.5 109 30.4 125 35.0 127 35.2 129 35.4 132 35.7 135 36.1
31 91.1 25.1 109 32.4 123 36.4 125 36.6 127 36.8 130 37.1 133 37.5
33 91.1 26.7 109 34.6 122 37.8 123 38.0 125 38.2 128 38.5 131 38.9
35 91.1 28.5 109 36.8 120 39.1 121 39.3 123 39.6 126 40.0 129 40.4
37 91.1 30.3 109 39.3 118 40.5 119 40.7 121 41.0 124 41.4 126 41.8
39 91.1 32.2 109 41.5 114 41.9 115 42.1 116 42.4 119 42.8 122 43.3
110 1,100 10 83.5 14.8 99.6 18.1 116 21.4 124 23.2 132 24.9 148 26.5 151 25.6
12 83.5 15.1 99.6 18.4 116 21.9 124 23.6 132 25.4 146 26.3 149 25.4
14 83.5 15.4 99.6 18.7 116 22.3 124 24.1 132 25.9 144 26.2 147 25.4
16 83.5 15.7 99.6 19.1 116 22.7 124 24.5 132 26.4 142 26.5 145 26.8
18 83.5 16.0 99.6 19.5 116 23.2 124 25.2 132 27.7 140 27.9 143 28.1
20 83.5 16.3 99.6 19.9 116 24.5 124 27.1 132 29.0 138 29.3 141 29.5
21 83.5 16.4 99.6 20.5 116 25.4 124 28.1 132 29.7 137 29.9 140 30.2
23 83.5 17.2 99.6 21.9 116 27.2 124 30.1 132 31.0 135 31.3 138 31.6
25 83.5 18.4 99.6 23.4 116 29.2 124 32.3 130 32.4 133 32.7 136 33.0
27 83.5 19.6 99.6 25.0 116 31.2 124 33.6 128 33.8 131 34.1 134 34.4
29 83.5 20.9 99.6 26.7 116 33.3 124 35.0 126 35.1 129 35.5 132 35.8
31 83.5 22.2 99.6 28.5 116 35.6 123 36.3 125 36.5 128 36.8 131 37.2
33 83.5 23.7 99.6 30.4 116 37.5 121 37.7 123 37.9 126 38.2 129 38.6
35 83.5 25.2 99.6 32.4 116 38.9 119 39.1 121 39.3 124 39.7 127 40.0
37 83.5 26.8 99.6 34.5 116 40.3 117 40.5 119 40.7 122 41.1 125 41.5
39 83.5 28.5 99.6 36.7 112 41.6 114 41.9 115 42.1 118 42.5 120 42.9
100 1,000 10 75.9 13.4 90.6 16.2 105 19.2 113 20.8 120 22.3 134 25.5 148 26.4
12 75.9 13.6 90.6 16.5 105 19.6 113 21.2 120 22.8 134 26.0 146 26.3
14 75.9 13.9 90.6 16.8 105 20.0 113 21.6 120 23.2 134 26.5 144 26.1
16 75.9 14.1 90.6 17.1 105 20.3 113 22.0 120 23.6 134 26.9 142 26.6
18 75.9 14.4 90.6 17.5 105 20.7 113 22.4 120 24.1 134 27.7 140 27.9
20 75.9 14.6 90.6 17.8 105 21.4 113 23.5 120 25.8 134 29.1 138 29.3
21 75.9 14.8 90.6 18.0 105 22.1 113 24.4 120 26.8 134 29.7 137 30.0
23 75.9 15.2 90.6 19.2 105 23.7 113 26.1 120 28.7 133 31.1 135 31.3
25 75.9 16.2 90.6 20.5 105 25.4 113 28.0 120 30.7 131 32.5 134 32.7
27 75.9 17.3 90.6 21.9 105 27.1 113 29.9 120 32.9 129 33.8 132 34.1
29 75.9 18.4 90.6 23.3 105 28.9 113 32.0 120 34.9 127 35.2 130 35.5
31 75.9 19.6 90.6 24.9 105 30.9 113 34.1 120 36.3 125 36.6 128 36.9
33 75.9 20.8 90.6 26.5 105 32.9 113 36.4 120 37.6 123 37.9 126 38.3
35 75.9 22.1 90.6 28.2 105 35.1 113 38.9 118 39.0 121 39.3 124 39.7
37 75.9 23.5 90.6 30.0 105 37.4 113 40.2 117 40.4 119 40.7 122 41.1
39 75.9 24.9 90.6 31.9 105 39.8 112 41.6 114 41.8 116 42.1 118 42.5
