• Systems • Outdoor Units
145
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-2 Heating capacity
3-2-20 44HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
50 550
-19.8 -20.0 69.5 37.2 69.4 38.0 68.8 38.3 66.5 36.9 64.3 35.4 59.9 32.6
-18.8 -19.0 72.1 37.7 72.0 38.5 68.8 36.7 66.5 35.3 64.3 33.9 59.9 31.3
-16.7 -17.0 77.2 38.7 73.2 36.3 68.8 33.8 66.5 32.5 64.3 31.3 59.9 28.9
-14.7 -15.0 77.6 36.1 73.2 33.7 68.8 31.3 66.5 30.2 64.3 29.1 59.9 26.9
-12.6 -13.0 77.6 33.6 73.2 31.4 68.8 29.2 66.5 28.2 64.3 27.1 59.9 25.1
-10.5 -11.0 77.6 31.4 73.2 29.4 68.8 27.4 66.5 26.4 64.3 25.5 59.9 23.6
-9.5-10.077.630.473.228.568.826.666.525.664.324.759.922.9
-8.5 -9.1 77.6 29.6 73.2 27.7 68.8 25.9 66.5 25.0 64.3 24.1 59.9 22.3
-7.0 -7.6 77.6 28.3 73.2 26.5 68.8 24.8 66.5 23.9 64.3 23.1 59.9 21.4
-5.0 -5.6 77.6 26.8 73.2 25.1 68.8 23.5 66.5 22.7 64.3 21.9 59.9 20.4
-3.0 -3.7 77.6 25.5 73.2 23.9 68.8 22.4 66.5 21.7 64.3 20.9 59.9 19.4
0.0 -0.777.623.773.222.368.820.966.520.264.319.559.918.2
3.0 2.2 77.6 22.2 73.2 20.9 68.8 19.6 66.5 19.0 64.3 18.4 59.9 17.1
5.0 4.1 77.6 21.4 73.2 20.1 68.8 18.9 66.5 18.3 64.3 17.7 59.9 16.5
7.0 6.0 77.6 20.6 73.2 19.4 68.8 18.2 66.5 17.6 64.3 17.0 59.9 15.9
9.0 7.9 77.6 19.8 73.2 18.7 68.8 17.6 66.5 17.0 64.3 16.5 59.9 15.4
11.0 9.8 77.619.273.218.168.817.066.516.564.315.959.914.9
13.0 11.8 77.6 18.5 73.2 17.5 68.8 16.4 66.5 15.9 64.3 15.4 59.9 14.4
15.0 13.7 77.6 17.9 73.2 16.9 68.8 15.9 66.5 15.5 64.3 15.0 59.9 14.0
NOTE
1 is shown as reference
When selecting the unit models, avoid the Outdoor air temperature range shown by .
