• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
18
1
• Systems • Outdoor Units
4
1 Specifications
1-2 Technical Specifications
1-2-1 5HP
RXYQ5M7W1B
NOMINAL CAPACITY Cooling kW 14.00
Heating kW 16.00
CAPACITY RANGE HP 5
POWER INPUT (NOMINAL) Cooling kW 3.79
Heating kW 4.34
MAX N° OF INDOOR UNITS TO BE CONNECTED 8
TOTAL CAPACITY INDEX OF INDOOR UNITS TO BE CONNECTED Min ~ max 62.5 ~ 162.5
CASING Colour Ivory White
Material Painted galvanised steel
DIMENSIONS Packing Height mm 1,829
Width mm 695
Depth mm 855
Unit Height mm 1,600
Width mm 635
Depth mm 765
WEIGHT Machine weight kg 160
Gross weight kg 184
HEAT EXCHANGER Specifications Length mm 1,345
N° of rows 54
Fin pitch mm 2.00
N° of passes 13
Face area m
2
1,598
N° of stages 2
Empty tubeplate hole 0
Tube type Hi-XSS (8)
Fin Type Non-symmetric waffle louvre
Treatment Corrosion resistant
FAN Type Propeller
Quantity 1
Air Flow Rate (230V) Cooling m
3
/min 75.00
Heating m
3
/min 75.00
External static pressure (MAX) Pa 60 Pa in high static pressure
Discharge direction Vertical
Motor Quantity 1
Model Brushless DC
Output W 350
Speed rpm 800
Drive Direct drive
COMPRESSOR Quantity 1
Motor Quantity 1
Model Inverter
Type Hermetically sealed scroll compressor
Speed rpm 1,900-6,480
Motor output kW 3.2
Starting method Direct on line
Crankcase heater W 33
OPERATION RANGE Cooling Minimum °CDB -5.0
Maximum °CDB 43.0
Heating Minimum °CWB -20.0
Maximum °CWB 15.5
SOUND LEVEL (NOMINAL) Cooling Sound Power dBA 72.0
Sound Pressure dBA 54.0
Heating Sound Pressure dBA 54.0
