Daikin RXYQ16M7W1B [64/182] Capacity tables
![Daikin RXYQ16M7W1B [64/182] Capacity tables](/views2/1707499/page64/bg40.png)
18
3
• Systems • Outdoor Units
63
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-1 Cooling capacity
3-1-15 34HP
34HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
90 765 10 58.3 9.93 69.5 12.0 80.8 14.1 86.4 15.3 92.0 16.4 103 18.7 114 21.1
12 58.3 10.1 69.5 12.2 80.8 14.4 86.4 15.5 92.0 16.7 103 19.1 114 21.5
14 58.3 10.3 69.5 12.4 80.8 14.7 86.4 15.8 92.0 17.0 103 19.5 114 21.9
16 58.3 10.5 69.5 12.6 80.8 15.0 86.4 16.1 92.0 17.4 103 19.8 114 22.3
18 58.3 10.6 69.5 12.9 80.8 15.2 86.4 16.5 92.0 17.7 103 20.2 114 23.0
20 58.3 10.8 69.5 13.1 80.8 15.5 86.4 16.8 92.0 18.4 103 21.7 114 24.1
21 58.3 10.9 69.5 13.3 80.8 15.8 86.4 17.4 92.0 19.0 103 22.5 114 24.7
23 58.3 11.1 69.5 13.8 80.8 16.9 86.4 18.6 92.0 20.4 103 24.2 113 25.8
25 58.3 11.7 69.5 14.7 80.8 18.1 86.4 19.9 92.0 21.8 103 25.9 112 26.9
27 58.3 12.5 69.5 15.7 80.8 19.3 86.4 21.3 92.0 23.3 103 27.7 110 28.0
29 58.3 13.3 69.5 16.8 80.8 20.6 86.4 22.7 92.0 24.9 103 29.0 108 29.2
31 58.3 14.1 69.5 17.8 80.8 22.0 86.4 24.2 92.0 26.6 103 30.1 107 30.3
33 58.3 15.0 69.5 19.0 80.8 23.4 86.4 25.8 92.0 28.3 103 31.2 105 31.5
35 58.3 15.9 69.5 20.2 80.8 24.9 86.4 27.5 92.0 30.2 101 32.4 103 32.6
37 58.3 16.9 69.5 21.5 80.8 26.5 86.4 29.3 92.0 32.2 99.6 33.5 102 33.8
39 58.3 18.0 69.5 22.8 80.8 28.3 86.4 31.2 92.0 34.3 98.0 34.7 100 34.9
80 680 10 51.88.8261.810.671.812.476.813.481.814.391.816.410218.4
12 51.88.9661.810.771.812.676.813.681.814.691.816.710218.8
14 51.89.1161.810.971.812.976.813.981.814.991.817.010219.1
16 51.89.2661.811.171.813.176.814.181.815.291.817.310219.5
18 51.89.4261.811.371.813.376.814.481.815.591.817.710219.9
20 51.89.5961.811.571.813.676.814.781.815.891.818.310221.3
21 51.89.6761.811.671.813.776.814.881.816.191.818.910222.0
23 51.89.8561.811.971.814.476.815.881.817.291.820.310223.6
25 51.8 10.2 61.8 12.6 71.8 15.4 76.8 16.9 81.8 18.4 91.8 21.7 102 25.3
27 51.8 10.8 61.8 13.5 71.8 16.4 76.8 18.0 81.8 19.7 91.8 23.2 102 27.1
29 51.8 11.5 61.8 14.3 71.8 17.5 76.8 19.2 81.8 21.0 91.8 24.8 102 28.9
31 51.8 12.2 61.8 15.2 71.8 18.6 76.8 20.5 81.8 22.4 91.8 26.5 102 30.1
33 51.8 13.0 61.8 16.2 71.8 19.8 76.8 21.8 81.8 23.8 91.8 28.2 102 31.2
35 51.8 13.7 61.8 17.2 71.8 21.1 76.8 23.2 81.8 25.4 91.8 30.1 101 32.3
37 51.8 14.6 61.8 18.3 71.8 22.4 76.8 24.7 81.8 27.0 91.8 32.1 99.3 33.5
39 51.8 15.4 61.8 19.4 71.8 23.9 76.8 26.3 81.8 28.8 91.8 34.2 97.7 34.6
70 595 10 45.47.7554.19.2062.810.767.211.571.612.480.314.089.015.8
12 45.47.8754.19.3562.810.967.211.771.612.680.314.389.016.1
14 45.47.9954.19.5162.811.167.212.071.612.880.314.689.016.4
16 45.48.1254.19.6762.811.367.212.271.613.080.314.989.016.7
18 45.48.2554.19.8462.811.567.212.471.613.380.315.189.017.0
20 45.48.3954.110.062.811.767.212.671.613.680.315.489.017.5
21 45.48.4754.110.162.811.967.212.871.613.780.315.789.018.1
23 45.48.6154.110.362.812.167.213.271.614.380.316.889.019.4
25 45.48.7754.110.762.812.967.214.171.615.380.317.989.020.8
27 45.49.2754.111.462.813.867.215.071.616.380.319.289.022.2
29 45.49.8354.112.162.814.667.216.071.617.480.320.489.023.7
31 45.4 10.4 54.1 12.9 62.8 15.6 67.2 17.0 71.6 18.6 80.3 21.8 89.0 25.3
33 45.4 11.1 54.1 13.7 62.8 16.6 67.2 18.1 71.6 19.7 80.3 23.2 89.0 27.0
35 45.4 11.7 54.1 14.5 62.8 17.6 67.2 19.3 71.6 21.0 80.3 24.7 89.0 28.8
37 45.4 12.4 54.1 15.4 62.8 18.7 67.2 20.5 71.6 22.3 80.3 26.3 89.0 30.6
39 45.4 13.1 54.1 16.3 62.8 19.8 67.2 21.7 71.6 23.7 80.3 28.0 89.0 32.6
60 510 10 38.96.7446.47.9153.99.1657.69.8161.310.568.811.876.313.3
12 38.96.8446.48.0453.99.3157.69.9761.310.768.812.176.313.5
14 38.96.9446.48.1653.99.4757.610.161.310.868.812.376.313.8
16 38.97.0446.48.3053.99.6357.610.361.311.068.812.576.314.0
18 38.97.1546.48.4353.99.8057.610.561.311.268.812.776.314.3
20 38.97.2646.48.5853.99.9757.610.761.311.468.813.076.314.6
21 38.97.3246.48.6553.910.157.610.861.311.668.813.176.314.7
23 38.97.4446.48.8053.910.357.611.061.311.868.813.676.315.7
25 38.97.5646.48.9653.910.757.611.661.312.568.814.576.316.7
27 38.97.8446.49.5053.911.357.612.361.313.368.815.576.317.8
29 38.98.3146.410.153.912.057.613.161.314.268.816.576.319.0
31 38.98.7946.410.753.912.857.613.961.315.168.817.676.320.3
33 38.99.3046.411.353.913.657.614.861.316.068.818.776.321.6
35 38.99.8446.412.053.914.457.615.761.317.068.819.976.323.0
37 38.9 10.4 46.4 12.7 53.9 15.3 57.6 16.7 61.3 18.1 68.8 21.2 76.3 24.5
39 38.9 11.0 46.4 13.5 53.9 16.2 57.6 17.7 61.3 19.2 68.8 22.5 76.3 26.0
