Daikin RXYQ16M7W1B [98/182] Capacity tables
![Daikin RXYQ16M7W1B [98/182] Capacity tables](/views2/1707499/page98/bg62.png)
18
3
• Systems • Outdoor Units
97
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-2 Heating capacity
3-2-4 12HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
50 150
-19.8 -20.0 19.0 10.3 18.9 10.6 18.8 10.6 18.1 10.2 17.5 9.84 16.3 9.06
-18.8 -19.0 19.7 10.5 19.6 10.7 18.8 10.2 18.1 9.80 17.5 9.42 16.3 8.68
-16.7 -17.0 21.1 10.7 20.0 10.1 18.8 9.38 18.1 9.03 17.5 8.69 16.3 8.02
-14.7 -15.0 21.2 10.0 20.0 9.34 18.8 8.70 18.1 8.38 17.5 8.07 16.3 7.45
-12.6 -13.0 21.2 9.31 20.0 8.71 18.8 8.11 18.1 7.82 17.5 7.53 16.3 6.97
-10.5 -11.0 21.2 8.71 20.0 8.15 18.8 7.61 18.1 7.34 17.5 7.07 16.3 6.55
-9.5-10.021.28.4420.07.9018.87.3818.17.1217.56.8616.36.36
-8.5 -9.1 21.2 8.21 20.0 7.69 18.8 7.18 18.1 6.93 17.5 6.69 16.3 6.20
-7.0 -7.6 21.2 7.86 20.0 7.37 18.8 6.88 18.1 6.65 17.5 6.41 16.3 5.95
-5.0 -5.6 21.2 7.44 20.0 6.98 18.8 6.52 18.1 6.30 17.5 6.08 16.3 5.65
-3.0 -3.7 21.2 7.08 20.0 6.64 18.8 6.22 18.1 6.01 17.5 5.80 16.3 5.40
0.0 -0.721.26.5820.06.1818.85.8018.15.6117.55.4216.35.04
3.0 2.2 21.2 6.17 20.0 5.80 18.8 5.44 18.1 5.27 17.5 5.09 16.3 4.75
5.0 4.1 21.2 5.93 20.0 5.58 18.8 5.24 18.1 5.07 17.5 4.90 16.3 4.58
7.0 6.0 21.2 5.71 20.0 5.38 18.8 5.05 18.1 4.89 17.5 4.73 16.3 4.42
9.0 7.9 21.2 5.50 20.0 5.19 18.8 4.88 18.1 4.72 17.5 4.57 16.3 4.27
11.0 9.8 21.25.3220.05.0118.84.7218.14.5717.54.4316.34.14
13.0 11.8 21.2 5.14 20.0 4.85 18.8 4.56 18.1 4.42 17.5 4.28 16.3 4.01
15.0 13.7 21.2 4.98 20.0 4.70 18.8 4.42 18.1 4.29 17.5 4.16 16.3 3.89
NOTE
1 is shown as reference
When selecting the unit models, avoid the Outdoor air temperature range shown by .
