Daikin RXYQ16M7W1B [144/182] Capacity tables
![Daikin RXYQ16M7W1B [144/182] Capacity tables](/views2/1707499/page144/bg90.png)
18
3
• Systems • Outdoor Units
143
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-2 Heating capacity
3-2-20 44HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
130 1,430
-19.8 -20.0 72.9 15.1 72.6 17.1 72.3 19.2 72.2 20.2 72.0 21.2 71.7 23.3
-18.8 -19.0 75.5 16.4 75.2 18.4 74.9 20.4 74.7 21.3 74.6 22.3 74.2 24.3
-16.7 -17.0 80.6 18.8 80.3 20.6 80.0 22.5 79.8 23.4 79.7 24.3 79.3 26.1
-14.7 -15.0 85.7 20.8 85.4 22.6 85.1 24.3 84.9 25.1 84.8 26.0 84.4 27.7
-12.6 -13.0 90.8 22.7 90.5 24.3 90.2 25.9 90.0 26.7 89.9 27.5 89.5 29.1
-10.5 -11.0 95.9 24.3 95.6 25.8 95.3 27.3 95.1 28.1 95.0 28.9 94.6 30.4
-9.5-10.098.525.098.126.597.828.097.728.797.529.597.231.0
-8.5 -9.1 101 25.6 100 27.1 100 28.5 100.0 29.3 99.8 30.0 99.5 31.4
-7.0 -7.6 105 26.6 104 28.0 104 29.4 104 30.1 104 30.8 103 32.2
-5.0 -5.6 110 27.8 109 29.2 109 30.5 109 31.2 109 31.8 108 33.2
-3.0 -3.7 115 28.9 114 30.2 114 31.4 114 32.1 114 32.7 113 34.0
0.0 -0.7 122 30.4 122 31.5 122 32.7 121 33.3 121 33.9 121 35.1
3.0 2.2 130 31.6 129 32.7 129 33.8 129 34.4 129 35.0 128 36.1
5.0 4.1 134 32.4 134 33.4 134 34.5 134 35.0 133 35.6 133 36.7
7.0 6.0 139 33.0 139 34.1 139 35.1 138 35.6 138 36.2 138 37.2
9.0 7.9 144 33.7 144 34.7 143 35.7 143 36.2 143 36.7 143 37.7
11.0 9.8 149 34.3 149 35.3 148 36.2 148 36.7 148 37.2 148 38.2
13.0 11.8 154 34.9 154 35.8 153 36.7 153 37.2 153 37.7 153 38.6
15.0 13.7 159 35.4 159 36.3 158 37.2 158 37.7 158 38.1 156 38.3
120 1,320
-19.8 -20.0 72.5 17.9 72.2 19.8 71.9 21.7 71.8 22.6 71.7 23.5 71.4 25.4
-18.8 -19.0 75.1 19.1 74.8 20.9 74.5 22.7 74.3 23.6 74.2 24.5 73.9 26.4
-16.7 -17.0 80.2 21.3 79.9 23.0 79.6 24.7 79.4 25.5 79.3 26.4 79.0 28.1
-14.7 -15.0 85.3 23.2 85.0 24.8 84.7 26.3 84.5 27.1 84.4 27.9 84.1 29.5
-12.6 -13.0 90.4 24.8 90.1 26.3 89.8 27.8 89.6 28.6 89.5 29.3 89.2 30.8
-10.5 -11.0 95.5 26.3 95.2 27.7 94.9 29.2 94.7 29.9 94.6 30.6 94.3 32.0
-9.5-10.098.027.097.728.497.429.897.330.597.231.196.932.5
-8.5 -9.1 100 27.6 100 28.9 99.7 30.3 99.6 31.0 99.5 31.6 99.2 33.0
-7.0 -7.6 104 28.5 104 29.8 104 31.1 103 31.7 103 32.4 103 33.7
-5.0 -5.6 109 29.6 109 30.9 109 32.1 109 32.7 108 33.3 108 34.5
-3.0 -3.7 114 30.6 114 31.8 114 32.9 113 33.5 113 34.1 113 35.3
0.0 -0.7 122 32.0 121 33.1 121 34.1 121 34.7 121 35.2 121 36.3
3.0 2.2 129 33.1 129 34.1 129 35.2 128 35.7 128 36.2 128 37.2
5.0 4.1 134 33.8 134 34.8 133 35.8 133 36.3 133 36.8 133 37.8
7.0 6.0 139 34.4 139 35.4 138 36.4 138 36.8 138 37.3 138 38.3
9.0 7.9 144 35.0 143 36.0 143 36.9 143 37.3 143 37.8 143 38.7
11.0 9.8 149 35.6 148 36.5 148 37.4 148 37.8 148 38.3 144 37.7
13.0 11.8 154 36.1 153 37.0 153 37.9 153 38.3 153 38.7 144 36.2
15.0 13.7 158 36.6 158 37.5 158 38.3 158 38.7 154 37.9 144 34.9
110 1,210
-19.8 -20.0 72.1 20.6 71.8 22.4 71.6 24.1 71.4 25.0 71.3 25.8 71.0 27.6
-18.8 -19.0 74.6 21.7 74.4 23.4 74.1 25.1 74.0 25.9 73.8 26.8 73.6 28.4
-16.7 -17.0 79.7 23.7 79.5 25.3 79.2 26.9 79.1 27.6 78.9 28.4 78.7 30.0
-14.7 -15.0 84.8 25.5 84.6 27.0 84.3 28.4 84.2 29.1 84.1 29.9 83.8 31.3
-12.6 -13.0 89.9 27.0 89.7 28.4 89.4 29.8 89.3 30.5 89.2 31.1 88.9 32.5
-10.5 -11.0 95.1 28.4 94.8 29.7 94.5 31.0 94.4 31.6 94.3 32.3 94.0 33.6
-9.5-10.097.629.097.330.397.131.596.932.296.832.896.534.1
-8.5 -9.1 99.9 29.6 99.6 30.8 99.4 32.0 99.2 32.6 99.1 33.2 98.8 34.5
-7.0 -7.6 104 30.4 103 31.6 103 32.8 103 33.4 103 33.9 103 35.1
-5.0 -5.6 109 31.4 109 32.6 108 33.7 108 34.2 108 34.8 108 35.9
-3.0 -3.7 114 32.3 113 33.4 113 34.5 113 35.0 113 35.5 113 36.6
0.0 -0.7 121 33.6 121 34.6 121 35.6 121 36.1 121 36.6 120 37.6
3.0 2.2 129 34.6 128 35.6 128 36.5 128 37.0 128 37.5 128 38.4
5.0 4.1 134 35.3 133 36.2 133 37.1 133 37.5 133 38.0 132 38.6
7.0 6.0 138 35.8 138 36.7 138 37.6 138 38.0 138 38.5 132 36.9
9.0 7.9 143 36.4 143 37.2 143 38.1 143 38.5 142 38.5 132 35.4
11.0 9.8 148 36.9 148 37.7 148 38.5 146 38.5 142 37.0 132 34.0
13.0 11.8 153 37.4 153 38.2 151 38.4 146 37.0 142 35.5 132 32.7
15.0 13.7 158 37.9 158 38.6 151 37.0 146 35.6 142 34.2 132 31.5
100 1,100
-19.8 -20.0 71.7 23.4 71.4 25.0 71.2 26.6 71.1 27.3 70.9 28.1 70.7 29.7
-18.8 -19.0 74.2 24.4 74.0 25.9 73.7 27.5 73.6 28.2 73.5 29.0 73.3 30.5
-16.7 -17.0 79.3 26.2 79.1 27.6 78.8 29.1 78.7 29.8 78.6 30.5 78.4 31.9
-14.7 -15.0 84.4 27.8 84.2 29.1 83.9 30.5 83.8 31.1 83.7 31.8 83.5 33.1
-12.6 -13.0 89.5 29.2 89.3 30.5 89.0 31.7 88.9 32.3 88.8 33.0 88.6 34.2
-10.5 -11.0 94.6 30.5 94.4 31.6 94.1 32.8 94.0 33.4 93.9 34.0 93.7 35.2
-9.5-10.097.231.096.932.296.733.396.633.996.534.596.235.6
-8.5 -9.1 99.5 31.5 99.2 32.6 99.0 33.8 98.9 34.3 98.7 34.9 98.5 36.0
-7.0 -7.6 103 32.3 103 33.4 103 34.4 103 35.0 103 35.5 102 36.6
-5.0 -5.6 108 33.2 108 34.2 108 35.3 108 35.8 108 36.3 107 37.3
-3.0 -3.7 113 34.0 113 35.0 113 36.0 113 36.5 113 37.0 112 37.9
0.0 -0.7 121 35.2 121 36.1 120 37.0 120 37.4 120 37.9 120 38.8
3.0 2.2 128 36.1 128 37.0 128 37.9 128 38.3 128 38.7 120 36.1
5.0 4.1 133 36.7 133 37.5 133 38.4 133 38.8 129 37.5 120 34.5
7.0 6.0 138 37.2 138 38.0
138 38.8 133 37.4 129 35.9 120 33.0
9.0 7.9 143 37.7 143 38.5 138 37.2 133 35.8 129 34.4 120 31.7
11.0 9.8 148 38.2 146 38.5 138 35.8 133 34.4 129 33.1 120 30.5
13.0 11.8 153 38.7 146 36.9 138 34.3 133 33.1 129 31.8 120 29.3
15.0 13.7 155 38.1 146 35.6 138 33.1 133 31.9 129 30.7 120 28.3
