• Systems • Outdoor Units
31
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-1 Cooling capacity
3-1-4 12HP
12HP
TC: Total capacity ; PI: Power input
Combination
(%)
Capacity index
Outdoor
air temp.
CDB
Indoor air temperature: CWB
14,0 16,0 18,0 19,0 20,0 22,0 24,0
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
50 150 10 11.31.9013.52.2015.72.5216.82.6817.82.8520.03.2022.23.56
12 11.31.9213.52.2315.72.5516.82.7217.82.9020.03.2522.23.63
14 11.31.9513.52.2615.72.5916.82.7717.82.9420.03.3122.23.69
16 11.31.9813.52.2915.72.6316.82.8117.82.9920.03.3722.23.76
18 11.32.0013.52.3315.72.6816.82.8617.83.0420.03.4322.23.83
20 11.32.0313.52.3715.72.7216.82.9117.83.1020.03.4922.23.90
21 11.32.0513.52.3915.72.7516.82.9317.83.1320.03.5222.23.94
23 11.32.0813.52.4215.72.7916.82.9917.83.1820.03.5922.24.03
25 11.32.1113.52.4615.72.8416.83.0517.83.2820.03.7722.24.30
27 11.32.1413.52.5515.73.0016.83.2417.83.4920.04.0122.24.58
29 11.32.2713.52.7015.73.1816.83.4417.83.7120.04.2722.24.87
31 11.32.3913.52.8615.73.3816.83.6517.83.9320.04.5422.25.19
33 11.32.5313.53.0315.73.5816.83.8717.84.1720.04.8222.25.51
35 11.32.6713.53.2015.73.7916.84.1017.84.4320.05.1222.25.86
37 11.32.8113.53.3815.74.0116.84.3417.84.6920.05.4322.26.22
39 11.32.9713.53.5715.74.2416.84.6017.84.9720.05.7622.26.61
