• Systems • Outdoor Units
127
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
3 Capacity tables
3-2 Heating capacity
3-2-14 32HP
TC: Total capacity; PI: Power Input
Combination (%) Capacity index
Outdoor
air temp.
Indoor air temperature: °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWBkWkWkWkWkWkWkWkWkWkWkWkW
50 400
-19.8 -20.0 50.6 26.9 50.5 27.5 50.0 27.7 48.4 26.6 46.8 25.6 43.6 23.6
-18.8 -19.0 52.4 27.3 52.3 27.8 50.0 26.5 48.4 25.5 46.8 24.5 43.6 22.6
-16.7 -17.0 56.1 27.9 53.2 26.3 50.0 24.4 48.4 23.5 46.8 22.6 43.6 20.9
-14.7 -15.0 56.4 26.0 53.2 24.3 50.0 22.6 48.4 21.8 46.8 21.0 43.6 19.4
-12.6 -13.0 56.4 24.2 53.2 22.7 50.0 21.1 48.4 20.4 46.8 19.6 43.6 18.1
-10.5 -11.0 56.4 22.7 53.2 21.2 50.0 19.8 48.4 19.1 46.8 18.4 43.6 17.0
-9.5-10.056.422.053.220.650.019.248.418.546.817.943.616.6
-8.5 -9.1 56.4 21.4 53.2 20.0 50.0 18.7 48.4 18.0 46.8 17.4 43.6 16.1
-7.0 -7.6 56.4 20.5 53.2 19.2 50.0 17.9 48.4 17.3 46.8 16.7 43.6 15.5
-5.0 -5.6 56.4 19.4 53.2 18.2 50.0 17.0 48.4 16.4 46.8 15.8 43.6 14.7
-3.0 -3.7 56.4 18.4 53.2 17.3 50.0 16.2 48.4 15.6 46.8 15.1 43.6 14.0
0.0 -0.756.417.153.216.150.015.148.414.646.814.143.613.1
3.0 2.2 56.4 16.1 53.2 15.1 50.0 14.2 48.4 13.7 46.8 13.3 43.6 12.4
5.0 4.1 56.4 15.4 53.2 14.5 50.0 13.6 48.4 13.2 46.8 12.8 43.6 11.9
7.0 6.0 56.4 14.9 53.2 14.0 50.0 13.1 48.4 12.7 46.8 12.3 43.6 11.5
9.0 7.9 56.4 14.3 53.2 13.5 50.0 12.7 48.4 12.3 46.8 11.9 43.6 11.1
11.0 9.8 56.413.853.213.150.012.348.411.946.811.543.610.8
13.0 11.8 56.4 13.4 53.2 12.6 50.0 11.9 48.4 11.5 46.8 11.1 43.6 10.4
15.0 13.7 56.4 13.0 53.2 12.2 50.0 11.5 48.4 11.2 46.8 10.8 43.6 10.1
NOTE
1 is shown as reference
When selecting the unit models, avoid the Outdoor air temperature range shown by .
