![Daikin RXYQ16M7W1B [14/182] Specifications](/img/pdf.png)
Daikin RXYQ16M7W1B [14/182] Specifications
![Daikin RXYQ24M8W1B [14/182] Specifications](/views2/1707499/page14/bge.png)
18
1
• Systems • Outdoor Units
13
• Inverter heat pump • RXYQ5M7W1B, RXYQ8,10M8W1B
1 Specifications
1-2 Technical Specifications
1-2-7 34~48HP
RXYQ-M8W1B 34 36 38 40 42 44 46 48
REFRIGERANT Type R-410A R-410A R-410A R-410A R-410A R-410A R-410A R-410A
Charge kg 32.1 33.6 35.4 36.9 38.4 40.2 41.7 43.2
Control Expansion valve (electronic type)
N° of circuits 33333333
REFRIGERANT OIL Type Synthetic (ether) oil
Charged Volume l (3x1.9)+(4x1.6) (3x1.9)+(4x1.6) (3x+1.9)+(4x1.6) (3x1.9)+(5x1.6) (3x1.9)+(5x1.6) (3x1.9)+(5x1.6) (3x1.9)+(6x1.6) (3x1.9)+(6x1.6)
PIPING CONNECTIONS Liquid Type Braze connection
Diameter (OD) mm 19.1 19.1 19.1 19.1 19.1 19.1 19.1 19.1
Gas Type Braze connection
Diameter (OD) mm 34.9 41.3 41.3 41.3 41.3 41.3 41.3 41.3
Oil equalizing Type Flare connection
Diameter (OD) mm 6.4 6.4 6.4 6.4 6.4 6.4 6.4 6.4
Heat Insulation Both liquid, gas and oil equalizing pipe
Max. total length m 300 300 300 300 300 300 300 300
DEFROST METHOD Reversed cycle
DEFROST CONTROL Sensor for outdoor heat exchanger temperature
CAPACITY CONTROL METHOD Inverter controlled
CAPACITY CONTROL 4 to 100 3 to 100
SAFETY DEVICES HPS
Fan motor overcurrent protector
Inverter overload protector
Over current relay
PC board fuse
STANDARD ACCESSORIES Item Installation and operation manual
Quantity 22222222
Item Connection pipes
Quantity 99999999
Item Additional refrigerant label
Quantity 33333333
3TW25801-4B
NOTES
1 Nominal cooling capacities are based on:
• Indoor temperature: 27°CDB, 19°CWB
• Outdoor temperature 35°CDB
• Equivalent refrigerant piping: 7.5m
• Level difference: 0m.
2 Nominal heating capacities are based on:
• Indoor temperature: 20°CDB
• Outdoor temperature: 7°CDB, 6°CWB
• Equivalent refrigerant piping: 7.5m
• Level difference : 0m.
3 Sound power level is an absolute value that a sound source generates.
4 Sound pressure level is a relative value, depending on the distance and
acoustic environment. For more details, please refer to sound level
drawings.
5 Sound values are measured in a semi-anechoic room.
