Capacity Tables (Heat Pump) ED34-645B
530 RXYQ-P
RXYQ54PY1, YL
[Explanation of symbols]
H
P
: Level difference (m) between indoor and outdoor units where indoor unit in inferior position
H
M
: Level difference (m) between indoor and outdoor units where indoor unit in superior position
L : Equivalent pipe length (m)
α : Rate of change in cooling/heating capacity
[Diameters of pipes (Standard size)]
Model Gas Liquid Model Gas Liquid Model Gas Liquid Model Gas Liquid
RXYQ5PY1, YL φ15.9 φ9.5 RXYQ18PY1, YL φ28.6 φ15.9 RXYQ30PY1, YL φ34.9 φ19.1 RXYQ42PY1, YL φ41.3 φ19.1
RXYQ8PY1, YL φ19.1 φ9.5 RXYQ20PY1, YL φ28.6 φ15.9 RXYQ32PY1, YL φ34.9 φ19.1 RXYQ44PY1, YL φ41.3 φ19.1
RXYQ10PY1, YL φ22.2 φ9.5 RXYQ22PY1, YL φ28.6 φ15.9 RXYQ34PY1, YL φ34.9 φ19.1 RXYQ46PY1, YL φ41.3 φ19.1
RXYQ12PY1, YL φ28.6 φ12.7 RXYQ24PY1, YL φ34.9 φ15.9 RXYQ36PY1, YL φ41.3 φ19.1 RXYQ48PY1, YL φ41.3 φ19.1
RXYQ14PY1, YL φ28.6 φ12.7 RXYQ26PY1, YL φ34.9 φ19.1 RXYQ38PY1, YL φ41.3 φ19.1 RXYQ50PY1, YL φ41.3 φ19.1
RXYQ16PY1, YL φ28.6 φ12.7 RXYQ28PY1, YL φ34.9 φ19.1 RXYQ40PY1, YL φ41.3 φ19.1 RXYQ52PY1, YL φ41.3 φ19.1
RXYQ54PY1, YL φ41.3 φ19.1
C: 3D053175B
