Capacity Tables (Heat Pump High COP Series) ED34-645B
594 RXYQ-PH
Heating capacity
Combin-
ation (%)
(Capacity
index)
Outdoor
air temp.
Indoor air temp. °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWB kW kW kW kW kW kW kW kW kW kW kW kW
70
(490)
-19.8 -20.0 54.6 22.0 54.4 22.5 54.3 23.1 54.3 23.3 54.2 23.6 53.4 23.6
-18.8 -19.0 55.9 22.2 55.8 22.7 55.7 23.3 55.7 23.5 55.6 23.8 53.4 22.9
-16.7 -17.0 58.8 22.7 58.7 23.2 58.6 23.7 58.5 23.9 57.3 23.4 53.4 21.5
-13.7 -15.0 61.8 23.1 61.6 23.6 61.3 23.9 59.3 23.0 57.3 22.0 53.4 20.2
-11.8 -13.0 64.8 23.5 64.7 24.0 61.3 22.5 59.3 21.6 57.3 20.8 53.4 19.1
-9.8 -11.0 68.0 23.9 65.2 22.9 61.3 21.2 59.3 20.4 57.3 19.6 53.4 18.0
-9.5 -10.0 69.1 23.8 65.2 22.2 61.3 20.6 59.3 19.8 57.3 19.0 53.4 17.5
-8.5 -9.1 69.1 23.2 65.2 21.6 61.3 20.1 59.3 19.3 57.3 18.6 53.4 17.1
-7.0 -7.6 69.1 22.2 65.2 20.7 61.3 19.2 59.3 18.5 57.3 17.8 53.4 16.4
-5.0 -5.6 69.1 21.0 65.2 19.6 61.3 18.2 59.3 17.5 57.3 16.9 53.4 15.6
-3.0 -3.7 69.1 19.9 65.2 18.6 61.3 17.3 59.3 16.7 57.3 16.0 53.4 14.8
0.0 -0.7 69.1 18.4 65.2 17.2 61.3 16.0 59.3 15.4 57.3 14.9 53.4 13.7
3.0 2.2 69.1 17.1 65.2 16.0 61.3 14.9 59.3 14.4 57.3 13.9 53.4 12.8
5.0 4.1 69.1 16.3 65.2 15.3 61.3 14.3 59.3 13.8 57.3 13.3 53.4 12.3
7.0 6.0 69.1 15.6 65.2 14.6 61.3 13.6 59.3 13.2 57.3 12.7 53.4 11.8
9.0 7.9 69.1 14.9 65.2 14.0 61.3 13.1 59.3 12.6 57.3 12.2 53.4 11.3
11.0 9.8 69.1 14.3 65.2 13.4 61.3 12.5 59.3 12.1 57.3 11.7 53.4 10.8
13.0 11.8 69.1 13.7 65.2 12.8 61.3 12.0 59.3 11.6 57.3 11.2 53.4 10.4
15.0 13.7 69.1 13.1 65.2 12.3 61.3 11.5 59.3 11.2 57.3 10.8 53.4 10.0
60
(420)
-19.8 -20.0 54.3 23.3 54.2 23.8 52.5 23.1 50.8 22.2 49.1 21.3 45.8 19.6
-18.8 -19.0 55.7 23.5 55.6 24.0 52.5 22.4 50.8 21.5 49.1 20.7 45.8 19.0
-16.7 -17.0 58.5 23.9 55.9 22.7 52.5 21.1 50.8 20.3 49.1 19.5 45.8 17.9
-13.7 -15.0 59.2 22.9 55.9 21.4 52.5 19.8 50.8 19.1 49.1 18.3 45.8 16.9
-11.8 -13.0 59.2 21.6 55.9 20.1 52.5 18.7 50.8 18.0 49.1 17.3 45.8 16.0
-9.8 -11.0 59.2 20.4 55.9 19.0 52.5 17.7 50.8 17.0 49.1 16.4 45.8 15.1
-9.5 -10.0 59.2 19.8 55.9 18.5 52.5 17.2 50.8 16.6 49.1 15.9 45.8 14.7
-8.5 -9.1 59.2 19.3 55.9 18.0 52.5 16.8 50.8 16.1 49.1 15.5 45.8 14.4
-7.0 -7.6 59.2 18.5 55.9 17.3 52.5 16.1 50.8 15.5 49.1 14.9 45.8 13.8
-5.0 -5.6 59.2 17.5 55.9 16.4 52.5 15.3 50.8 14.7 49.1 14.2 45.8 13.1
-3.0 -3.7 59.2 16.7 55.9 15.6 52.5 14.5 50.8 14.0 49.1 13.5 45.8 12.5
0.0 -0.7 59.2 15.4 55.9 14.5 52.5 13.5 50.8 13.0 49.1 12.6 45.8 11.7
3.0 2.2 59.2 14.4 55.9 13.5 52.5 12.6 50.8 12.2 49.1 11.7 45.8 10.9
5.0 4.1 59.2 13.7 55.9 12.9 52.5 12.1 50.8 11.7 49.1 11.3 45.8 10.5
7.0 6.0 59.2 13.2 55.9 12.4 52.5 11.6 50.8 11.2 49.1 10.8 45.8 10.0
9.0 7.9 59.2 12.6 55.9 11.8 52.5 11.1 50.8 10.7 49.1 10.4 45.8 9.7
11.0 9.8 59.2 12.1 55.9 11.4 52.5 10.7 50.8 10.3 49.1 10.0 45.8 9.3
13.0 11.8 59.2 11.6 55.9 10.9 52.5 10.2 50.8 9.9 49.1 9.6 45.8 8.93
15.0 13.7 59.2 11.1 55.9 10.5 52.5 9.9 50.8 9.5 49.1 9.2 45.8 8.61
50
(350)
-19.8 -20.0 49.4 21.5 46.6 20.0 43.8 18.6 42.3 17.9 40.9 17.2 38.1 15.9
-18.8 -19.0 49.4 20.8 46.6 19.4 43.8 18.0 42.3 17.4 40.9 16.7 38.1 15.4
-16.7 -17.0 49.4 19.6 46.6 18.3 43.8 17.0 42.3 16.4 40.9 15.8 38.1 14.6
-13.7 -15.0 49.4 18.5 46.6 17.2 43.8 16.1 42.3 15.5 40.9 14.9 38.1 13.8
-11.8 -13.0 49.4 17.4 46.6 16.3 43.8 15.2 42.3 14.6 40.9 14.1 38.1 13.0
-9.8 -11.0 49.4 16.5 46.6 15.4 43.8 14.4 42.3 13.9 40.9 13.4 38.1 12.4
-9.5 -10.0 49.4 16.0 46.6 15.0 43.8 14.0 42.3 13.5 40.9 13.0 38.1 12.1
-8.5 -9.1 49.4 15.6 46.6 14.6 43.8 13.7 42.3 13.2 40.9 12.7 38.1 11.8
-7.0 -7.6 49.4 15.0 46.6 14.1 43.8 13.2 42.3 12.7 40.9 12.2 38.1 11.4
-5.0 -5.6 49.4 14.3 46.6 13.4 43.8 12.5 42.3 12.1 40.9 11.7 38.1 10.8
-3.0 -3.7 49.4 13.6 46.6 12.8 43.8 11.9 42.3 11.5 40.9 11.1 38.1 10.4
0.0 -0.7 49.4 12.6 46.6 11.9 43.8 11.1 42.3 10.8 40.9 10.4 38.1 9.7
3.0 2.2 49.4 11.8 46.6 11.1 43.8 10.4 42.3 10.1 40.9 9.7 38.1 9.09
5.0 4.1 49.4 11.3 46.6 10.7 43.8 10.0 42.3 9.7 40.9 9.4 38.1 8.73
7.0 6.0 49.4 10.9 46.6 10.2 43.8 9.6 42.3 9.3 40.9 9.00 38.1 8.40
9.0 7.9 49.4 10.4 46.6 9.8 43.8 9.2 42.3 8.95 40.9 8.66 38.1 8.09
11.0 9.8 49.4 10.0 46.6 9.5 43.8 8.89 42.3 8.62 40.9 8.34 38.1 7.80
13.0 11.8 49.4 9.6 46.6 9.1 43.8 8.55 42.3 8.29 40.9 8.03 38.1 7.52
15.013.749.4 9.3 46.68.7643.88.2542.38.0040.97.7538.17.26
TC Total capacity ; kW
PI Power Input ; kW(Comp.+Outdoor fan motor)
Note1: is shown as reference.
When selecting the unit models, avoid the Outdoor air temperature range shown by .
Note2: The above table shows the average value of conditions which may occur.
