Daikin RXYQ30PY1 [425/487] 3 when operating with momentary input from a use a momentary input of on time 200 milli sec or longer
![Daikin RXYQ46PY1 [425/487] 3 when operating with momentary input from a use a momentary input of on time 200 milli sec or longer](/views2/1711913/page425/bg1a9.png)
ED34-645B Adaptor
Control 817
16
(3) When operating with momentary input from A
(Use a momentary input of ON time 200 milli-sec. or longer.)
For demand control from input B
Forced thermostat OFF command
Forces indoor unit to operate the fan only.
Forced temperature shift command
The indoor unit operates at 2°C higher (cooling) or 2°C lower (heating) than the set temperature.
Note:
In zone control, operation is displayed as long as one indoor unit is running. When in the last command priority
mode, some units are not operating while ON.
In such case, even if input A is ON, the unit and all other units in the same zone will stop.
(4) When operating with dual momentary inputs from A and B (Use a momentary input of 200 milli-sec. or longer.)
Note:
Doing constant input A with position 7-A, it will be forced OFF function (input A is ignored).
Constant input cannot use for input B with position B.
1PA63642B
Position Function Contents of Input A Function of Input B
5 Remote Controller Rejected
Stop for ON while operating, Operate for ON while
stopping
Input B will be forced stop
function (When ON, stop +
remote controller is rejected,
input A is ignored.)
6 Last Command Priority
Stop for ON while operating, Operate for ON while
stopping (Remote controller is normally accepted.)
Position Function when input A is ON Function when input B is ON
C
Remote controller rejected (Same as position”5”)
Forced thermostat OFF command
D Forced temperature shift command
E
Last command priority (Same as position “6”)
Forced thermostat OFF command
F Forced temperature shift command
Position Function Contents when Input A is ON Contents when Input A is OFF
7 Remote Controller Rejection Operation (remote controller is normally rejected)
Stop + remote controller
rejection
8 Central Priority Operation + remote controller accepted
9
Stop by Remote Controller
Acceptable
Operation + stop by remote controller acceptable (No
operation by the remote controller)
A
Remote Controller
Acceptance/Rejection
Remote controller acceptance only (No operation by
the remote location)
B Last Command Priority Operation (remote controller is normally accepted)
Stop (remote controller normally
accepted)
