Capacity Tables (Heat Pump High COP Series) ED34-645B
600 RXYQ-PH
Heating capacity
Combin-
ation (%)
(Capacity
index)
Outdoor
air temp.
Indoor air temp. °CDB
16.0 18.0 20.0 21.0 22.0 24.0
TC PI TC PI TC PI TC PI TC PI TC PI
°CDB °CWB kW kW kW kW kW kW kW kW kW kW kW kW
70
(599)
-19.8 -20.0 65.8 28.0 65.7 28.6 65.5 29.3 65.5 29.7 65.4 30.0 65.0 30.5
-18.8 -19.0 67.0 28.2 66.9 28.9 66.7 29.6 66.7 29.9 66.6 30.2 65.0 29.8
-16.7 -17.0 69.7 28.7 69.5 29.3 69.4 30.0 69.3 30.3 69.3 30.6 65.0 28.4
-13.7 -15.0 72.6 29.2 72.5 29.8 72.3 30.4 72.2 30.6 69.8 29.4 65.0 27.0
-11.8 -13.0 75.9 29.6 75.7 30.3 74.6 30.2 72.2 29.0 69.8 27.8 65.0 25.5
-9.8 -11.0 79.4 30.1 79.3 30.7 74.6 28.5 72.2 27.4 69.8 26.3 65.0 24.2
-9.5 -10.0 81.3 30.4 79.3 29.9 74.6 27.7 72.2 26.6 69.8 25.5 65.0 23.5
-8.5 -9.1 83.1 30.6 79.3 29.1 74.6 26.9 72.2 25.9 69.8 24.9 65.0 22.9
-7.0 -7.6 84.1 29.8 79.3 27.8 74.6 25.8 72.2 24.8 69.8 23.8 65.0 21.9
-5.0 -5.6 84.1 28.0 79.3 26.1 74.6 24.2 72.2 23.3 69.8 22.4 65.0 20.7
-3.0 -3.7 84.1 26.4 79.3 24.6 74.6 22.9 72.2 22.0 69.8 21.2 65.0 19.6
0.0 -0.7 84.1 24.1 79.3 22.5 74.6 20.9 72.2 20.1 69.8 19.4 65.0 17.9
3.0 2.2 84.1 22.0 79.3 20.6 74.6 19.2 72.2 18.5 69.8 17.8 65.0 16.5
5.0 4.1 84.1 20.8 79.3 19.4 74.6 18.1 72.2 17.5 69.8 16.9 65.0 15.6
7.0 6.0 84.1 19.6 79.3 18.4 74.6 17.2 72.2 16.6 69.8 16.0 65.0 14.8
9.0 7.9 84.1 18.6 79.3 17.4 74.6 16.3 72.2 15.7 69.8 15.1 65.0 14.1
11.0 9.8 84.1 17.6 79.3 16.5 74.6 15.4 72.2 14.9 69.8 14.4 65.0 13.4
13.0 11.8 84.1 16.6 79.3 15.6 74.6 14.6 72.2 14.1 69.8 13.6 65.0 12.7
15.0 13.7 84.1 15.8 79.3 14.8 74.6 13.9 72.2 13.4 69.8 13.0 65.0 12.1
60
(513)
-19.8 -20.0 65.5 29.7 65.4 30.3 63.9 29.9 61.8 28.7 59.8 27.6 55.7 25.3
-18.8 -19.0 66.7 29.9 66.6 30.5 63.9 29.2 61.8 28.1 59.8 26.9 55.7 24.7
-16.7 -17.0 69.3 30.3 68.0 30.0 63.9 27.8 61.8 26.7 59.8 25.7 55.7 23.6
-13.7 -15.0 72.1 30.6 68.0 28.5 63.9 26.4 61.8 25.4 59.8 24.4 55.7 22.5
-11.8 -13.0 72.1 29.0 68.0 27.0 63.9 25.0 61.8 24.1 59.8 23.2 55.7 21.3
-9.8 -11.0 72.1 27.4 68.0 25.5 63.9 23.7 61.8 22.8 59.8 21.9 55.7 20.2
-9.5 -10.0 72.1 26.6 68.0 24.8 63.9 23.0 61.8 22.2 59.8 21.3 55.7 19.7
-8.5 -9.1 72.1 25.9 68.0 24.1 63.9 22.4 61.8 21.6 59.8 20.8 55.7 19.2
-7.0 -7.6 72.1 24.8 68.0 23.1 63.9 21.5 61.8 20.7 59.8 19.9 55.7 18.4
-5.0 -5.6 72.1 23.3 68.0 21.8 63.9 20.3 61.8 19.5 59.8 18.8 55.7 17.4
-3.0 -3.7 72.1 22.0 68.0 20.6 63.9 19.2 61.8 18.5 59.8 17.8 55.7 16.5
0.0 -0.7 72.1 20.1 68.0 18.8 63.9 17.6 61.8 17.0 59.8 16.4 55.7 15.2
3.0 2.2 72.1 18.5 68.0 17.3 63.9 16.2 61.8 15.6 59.8 15.1 55.7 14.0
5.0 4.1 72.1 17.5 68.0 16.4 63.9 15.3 61.8 14.8 59.8 14.3 55.7 13.3
7.0 6.0 72.1 16.6 68.0 15.5 63.9 14.6 61.8 14.1 59.8 13.6 55.7 12.6
9.0 7.9 72.1 15.7 68.0 14.7 63.9 13.8 61.8 13.4 59.8 12.9 55.7 12.0
11.0 9.8 72.1 14.9 68.0 14.0 63.9 13.1 61.8 12.7 59.8 12.3 55.7 11.5
13.0 11.8 72.1 14.1 68.0 13.3 63.9 12.5 61.8 12.1 59.8 11.7 55.7 10.9
15.0 13.7 72.1 13.4 68.0 12.6 63.9 11.9 61.8 11.5 59.8 11.1 55.7 10.4
50
(428)
-19.8 -20.0 60.1 27.7 56.7 25.8 53.3 24.0 51.5 23.1 49.8 22.2 46.4 20.5
-18.8 -19.0 60.1 27.1 56.7 25.3 53.3 23.5 51.5 22.6 49.8 21.7 46.4 20.0
-16.7 -17.0 60.1 25.8 56.7 24.1 53.3 22.4 51.5 21.6 49.8 20.8 46.4 19.2
-13.7 -15.0 60.1 24.6 56.7 22.9 53.3 21.3 51.5 20.6 49.8 19.8 46.4 18.3
-11.8 -13.0 60.1 23.3 56.7 21.8 53.3 20.3 51.5 19.5 49.8 18.8 46.4 17.4
-9.8 -11.0 60.1 22.1 56.7 20.6 53.3 19.2 51.5 18.5 49.8 17.8 46.4 16.5
-9.5 -10.0 60.1 21.4 56.7 20.1 53.3 18.7 51.5 18.0 49.8 17.4 46.4 16.1
-8.5 -9.1 60.1 20.9 56.7 19.6 53.3 18.3 51.5 17.6 49.8 17.0 46.4 15.7
-7.0 -7.6 60.1 20.0 56.7 18.8 53.3 17.5 51.5 16.9 49.8 16.3 46.4 15.1
-5.0 -5.6 60.1 18.9 56.7 17.7 53.3 16.6 51.5 16.0 49.8 15.4 46.4 14.3
-3.0 -3.7 60.1 17.9 56.7 16.8 53.3 15.7 51.5 15.2 49.8 14.7 46.4 13.6
0.0 -0.7 60.1 16.5 56.7 15.5 53.3 14.5 51.5 14.0 49.8 13.5 46.4 12.6
3.0 2.2 60.1 15.2 56.7 14.3 53.3 13.4 51.5 12.9 49.8 12.5 46.4 11.7
5.0 4.1 60.1 14.4 56.7 13.5 53.3 12.7 51.5 12.3 49.8 11.9 46.4 11.1
7.0 6.0 60.1 13.7 56.7 12.9 53.3 12.1 51.5 11.7 49.8 11.3 46.4 10.6
9.0 7.9 60.1 13.0 56.7 12.2 53.3 11.5 51.5 11.1 49.8 10.8 46.4 10.1
11.0 9.8 60.1 12.4 56.7 11.7 53.3 11.0 51.5 10.6 49.8 10.3 46.4 9.6
13.0 11.8 60.1 11.7 56.7 11.1 53.3 10.4 51.5 10.1 49.8 9.8 46.4 9.2
15.0 13.7 60.1 11.2 56.7 10.6 53.3 10.0 51.5 9.7 49.8 9.4 46.4 8.79
TC Total capacity ; kW
PI Power Input ; kW(Comp.+Outdoor fan motor)
Note1: is shown as reference.
When selecting the unit models, avoid the Outdoor air temperature range shown by .
Note2: The above table shows the average value of conditions which may occur.
