ED34-645B Control System
Control 703
16
Outline of System
Relevant
Page
Number
Individual Control (Controls Indoor Units Individually.)
KRP1B61,KRP1C3,KRP2A61,62
and KRP4A51,52,53 can be built-in
together into the indoor units
Combined use of wiring adaptor for
Electrical Appendices (1) and (2) is not
available.
819
Group Unified Control (Controls group controlled indoor units all at once and simultaneously.)
Zone Unified Control (Unified, simultaneous control of up to 64 groups of group controlled
indoor units consisting of up to 16 units each.)
812
844
846
704
709
788
∗
Be sure to provide a master remote
controller.
This scheduled operation cannot be
used in both cases at control by two
remote controllers and at the
connection of a group remote
control adaptor.
Wired remote controller
with weekly schedule timer
Remote controller
Wired remote controller
with weekly schedule timer
Remote controller
