Planet BM-525 [12/205] Modify the administrator s password

BM-525 Bandwidth Management Gateway User’s Manual

- 7 -

Modify the Administrator’s Password

STEP 1﹒In the Admin Web UI, locate the Administrator name you want to edit, and click on

Modify in the ConFigure field.

STEP 2﹒The Modify Administrator Password Web UI will appear. Enter the following

information:

 Password: admin

 New Password: 52364

 Confirm Password: 52364

STEP 3﹒Click OK to confirm password change.

Modify Admin Password
