BM-525 Bandwidth Management Gateway User’s Manual
- 2 -
1.2 Package Contents
The following items should be included:
♦ Bandwidth Management Gateway
♦ Power Adapter
♦ Quick Installation Guide
♦ User’s Manual CD
If any of the contents are missing or damaged, please contact your dealer or distributor immediately.
1.3 Bandwidth Management Gateway Top View
LED Description
PWR Power is supplied to this device.
WAN Steady on indicates the port is connected to other network
device.
Blink to indicates there is traffic on the port
LAN Steady on indicates the port is connected to other network
device.
Blink to indicates there is traffic on the port
DMZ Steady on indicates the port is connected to other network
device.
Blink to indicates there is traffic on the port
1.4 Bandwidth Management Gateway Rear Panel
Port or button Description
Power 12V DC, 1.5A
RESET
Press this button to restore to factory default settings.
WAN
Connect to your xDSL/Cable modem or other Internet
connection device
