![Planet BM-525 [8/205] Specification](/views2/1071667/page8/bg8.png)
BM-525 Bandwidth Management Gateway User’s Manual
- 3 -
LAN
Connect to your local PC, switch, or other local network
device
DMZ
Connect to your local PC, switch, or other local network
device
1.5 Specification
Product Bandwidth Management Gateway
Model BM-525
Hardware
WAN 1 x 10/100Base-TX Connections
LAN
DMZ
1 x 10/100Base-TX, Auto-MDI/MDI-X
1 x 10/100Base-TX, Auto-MDI/MDI-X
Button Reset button for hardware reset / factory default
System LED PWR, WAN, LAN, DMZ
Software
Maximum Bandwidth 25Mbps
Maximum concurrent
session
20,000
Management Web (English, Traditional Chinese, Simplified Chinese)
Operation Mode DMZ_NAT, DMZ_Transparent, NAT
WAN connection type in
NAT mode
PPPoE, DHCP, and Fixed IP
Traffic Classification IP, IP subnet, and TCP/UDP port
Bandwidth Allocation Policy rules with Inbound/Outbound traffic management
Guaranteed and maximum bandwidth
Scheduled in unit of 30 minutes
3 Priorities
Log Traffic Log, Event Log, Connection Log, Log backup by mail or
syslog server
Statistics WAN port statistics and policy statistics with graph display
Firewall Security Policy-based access control
Stateful Packet Inspection (SPI)
Scheduled in unit of 30 minutes
Hacker Alert and
Anomaly Flow Detection
Detect SYN Attack, Detect ICMP Flood, Detect UDP Flood,
Detect Ping of Death Attack, Detect Tear Drop Attack, Detect IP
Spoofing Attack, Filter IP Route Option, Detect Port Scan Attack,
Detect Land Attack, Virus-Infected Blocking, E-Mail Alert
Notification, NetBIOS Notification
Alarm Traffic alarm for user-defined traffic level
Event alarm for hacker attack
The alarm message can sent to administrator by e-mail
Other Functions Firmware Upgradeable through Web
NTP support
Configuration Backup and Restore through Web
Dynamic DNS support
Multiple NAT and multiple DMZ (mapped IP) support
Multiple server load balancing
