BM-525 Bandwidth Management Gateway User’s Manual

- 21 -

Reboot BM-525

STEP 1﹒Reboot BM-525：Click Reboot button next to Reboot BM-525 Appliance.

STEP 2﹒A confirmation pop-up page will appear.

STEP 3﹒Follow the confirmation pop-up page; click OK to restart BM-525.

Reboot BM-525
