BM-525 Bandwidth Management Gateway User’s Manual

- 199 -

7.16 ARP Table

STEP 1﹒Enter ARP Table in Status function; it will display a table about IP Address, MAC

Address, and the Interface information which is connecting to the BM-525.

 NetBIOS Name: The identified name of the network

 IP Address: The IP Address of the network

 MAC Address: The identified number of the network card

 Interface: The Interface of the computer

ARP Table Web UI
