Planet BM-525 [141/205] Only allow the users who pass authentication to access to internet in particular time

BM-525 Bandwidth Management Gateway User’s Manual

- 136 -

Only allow the users who pass Authentication to access to Internet in particular

time

STEP 1﹒Enter the following in Schedule function.

Add New Schedule

STEP 2﹒Enter the following in Auth User and Auth User Group in Authentication function.

Setting Auth User Group

The Administrator can use group function the Authentication and Service. It is more convenient

when setting policy.
