BM-525 Bandwidth Management Gateway User’s Manual

- 158 -

We set up four LOG examples in the section:

No. Suitable

Situation

Example

Ex 1

Traffic Log

To detect the information and Protocol port that users

use to access to Internet or Intranet by BM-525.

Ex 2

Event Log

To record the detailed management events (such as

Interface and event description of BM-525) of the

Administrator

Ex 3

Connection

Log

To detect event description of WAN Connection

Ex 4

Log Backup

To save or receive the records that sent by the

BM-525
