BM-525 Bandwidth Management Gateway User’s Manual

- 25 -

WAN Interface can use Assist to enter the data.

After setting, there will be two subnets in LAN: 192.168.1.0/24 (default LAN subnet) and

172.16.30.0/24. So if LAN IP is:

192.168.1.xx, it must use NAT Mode to connect to the Internet.

162.172.50.xx, it’s also use NAT mode through WAN (The Internet Server can see your WAN IP directly).

Multiple Subnet Network

 The BM-525’s Interface Status:

WAN IP：211.22.22.22

LAN Port IP：192.168.1.1

LAN Port Multiple Subnet：172.16.30.1
