BM-525 Bandwidth Management Gateway User’s Manual

- 41 -

We set up four Interface Address examples in this section:

No. Suitable

Situation

Example

Ex1

LAN

Modify LAN Interface Settings

Ex2

WAN

Setting WAN Interface Address

Ex3

DMZ

Setting DMZ Interface Address (NAT Mode)

Ex4

DMZ

Setting DMZ Interface Address (Transparent Mode)
