BM-525 Bandwidth Management Gateway User’s Manual

- 84 -

We set up four Authentication examples in this section:

No Suitable

Situation

Example

Ex1

Auth User

Auth Group

Setting specific users to connect with external

network, only those pass the authentication of

policy.

（Adopt the built-in Auth User and Auth Group

Function）
