97
9
MEMORY/CALL CHANNELS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
N Programming memory/bank/scan name
Each memory channel can be programmed with an alpha-
numeric channel name for easy recognition and can be indi-
cated independently by channel. Names can be a maximum
of 8 characters. (Bank name is up to 6 characters.)
NOTE: Scan name indication can be turned ON or OFF in
DISP set mode (SET).
(p. 130)
q Push [M/CALL] to select memory mode.
w Push and hold [S.MW](M/CALL) for 1 sec. to enter select
memory write mode.
• 1 short and 1 long beep sound.
• “
” indication and memory channel number blink.
e Rotate [DIAL] to select the desired memory channel.
• Select call channels (C0 or C1) or scan edge channels (0A/0B
to 24A/24B) to program a call channel name or scan name, re-
spectively.
r Push [∫](2) or [√](8) several times to select “B NAME,”
“M NAME” or “S NAME” when programming the bank
name, the memory name or the scan name, respectively.
• After selecting the name to be programmed, a cursor blinks for
the first character.
t Rotate [DIAL] to select the desired character.
• The selected character blinks.
• Push [](6) to move the cursor right; push [](4) to move the
cursor left.
• Push [CLR](1) to erase the selected character, or push and hold
[CLR](1) for 1 sec. to erase all characters following the cursor.
y Repeat step t until the desired channel name is pro-
grammed.
u Push and hold [S.MW](M/CALL) for 1 sec. to set the name
and exit channel name programming state.
• 3 beeps sound.
NOTE: Only one bank name can be programmed into each
bank. Therefore, the previously programmed bank name
will be displayed when bank name indication is selected.
Also, the programmed bank name is assigned for the other
bank channels automatically.
D Available characters
(A) (B) (C) (D) (E) (F) (G) (H) (
I
) (J)
(Space)
(K) (L) (M)
(N) (O) (P) (Q) (R) (S) (T) (U) (V) (W)
(9)(0) (1) (2) (3) (4) (5) (6) (7) (8)
(
+
)
(
”
)(
!
) (#) ($) (%) (&) (
’
)
(
.
)(
:
)(
;
)(
=
) (?) (@) (
[
)(
\
)(
]
)(
^
)
(
(
)(
)
)(
)
(X) (Y) (Z)
(
,
)(
-
)
(
/
)(
<
)(
>
)
