D Dial speed acceleration (DIAL S)
The dial speed acceleration automatically speeds up the tun-
ing dial speed when rotating [DIAL] rapidly.
• OFF : The dial speed acceleration is turned OFF.
• ON : The dial speed acceleration is tuned ON.
(default)
D Active band (ACTIVE)
Allows continuous frequency selection of the operating fre-
quency across all bands.
• SINGLE : A single operating frequency can be se
-
lected within the current band. Push
[BAND] for band selection in this case.
• ALL : The operating frequency can be selected
continuously. (default)
D Key lock type (LOCK)
While the key lock function is ON, [PWR], [PTT], [SQL],
[VOL] and [MENU](
Lock function only) can still be accessed.
Accessible keys can be set to 1 of 4 groups.
• NORMAL :
[PWR], [PTT], [SQL], [VOL] and [MENU]
(Lock function only) accessible. (default)
• NO SQL : [PWR], [PTT], [VOL] and [MENU] (Lock func-
tion only) are accessible.
• NO VOL :
[PWR], [PTT], [SQL] and [MENU]
(Lock func-
tion only) are accessible.
• ALL :
[PWR], [PTT] and [MENU]
(Lock function only)
are accessible.
