Icom IC-80AD [165/188] Display backlighting
![Icom IC-80AD [165/188] Display backlighting](/views2/1074077/page165/bga5.png)
157
13
OTHER FUNCTIONS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
N Time-out timer
To prevent accidental prolonged transmission, etc., the
transceiver has a time-out timer. This timer cuts a trans-
mission OFF after 1, 3, 5, 15 or 30 min. of continuous
transmission. This timer can be cancelled (default).
Approx. 10 sec. before the time-out timer is activated, the
transceiver emits a beep tone as a warning.
This can be selected with “TOT” in FUNC set mode (SET).
MENU ¶ SET ¶ FUNC ¶ TOT
(p. 126)
(Push [MENU ]), (Push [](2)/[](8), then push [ ](5).)
N PTT lock
To prevent accidental transmission, etc., the transceiver has
a PTT lock function.
This can be selected with “PTT LK” in FUNC set mode
(SET).
MENU ¶ SET ¶ FUNC ¶ PTT LK
(p. 125)
(Push [MENU ]), (Push [](2)/[](8), then push [ ](5).)
N Display backlighting
The transceiver has display backlighting with a 5 sec. timer
for night time operation (AUTO1/AUTO2*). The display back-
lighting can be turned ON continuously or turned OFF, if de-
sired.
* AUTO2 is same as AUTO1 with battery pack or batteries case op-
eration, and display backlight stays ON when using the external
power supply (more than 10 V DC).
MENU ¶ SET ¶ DISP ¶ LIGHT
(p. 129)
(Push [MENU ]), (Push [](2)/[](8), then push [ ](5).)
N LCD contrast
The contrast of the LCD can be selected from 4 levels.
MENU ¶ SET ¶ DISP ¶ CONT
(p. 129)
(Push [MENU ]), (Push [](2)/[](8), then push [ ](5).)
