D GPS memory clearing
• Clear all memory channels
q Enter “GPS.MEM” in GPS set mode.
MENU ¶ GPS ¶ GPS.MEM
(Push [MENU ]), (Push [](2)/[](8), then push [ ](5).)
• GPS memory selection screen is displayed.
w Push [](2) or [](8) to select “CLEAR ALL,” then push
[
](5).
• “CLEAR OK?” appears.
e Push [ ](5) again to clear all memory channels.
• 2 beep sounds, then all memory channels are cleared.
r Push [ ](4) to return to GPS.MEM (GPS memory)
screen.
t Push [MENU
] to return to frequency indication.
• Clear desired memory channel to be cleared
q Enter “GPS.MEM” in GPS set mode as described at left.
w Push [](2) or [](8) to select the desired GPS memory
channel to be cleared, then push [](6).
e Push [](8) several times to select “CLEAR,” then push
[ ](5).
• “CLEAR OK?” appears.
r Push [ ](5) again to clear the list.
• 2 beep sounds, then the selected memory channel is cleared.
• Remaining channels scroll up.
t Push [ ](4) to return to GPS.MEM (GPS memory)
screen.
y Push [MENU
] to return to frequency indication.
