95
11
MENU SCREEN OPERATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
DD
GPS auto TX timer
Selects the desired interval for automatic position transmis-
sion function from 5, 10, 30 second, 1, 3, 5, 10 and 30 min-
utes.
(default: OFF)
DD
DV auto detect
When a signal other than DV mode is received during DV
mode operation, the transceiver has capability of automatic
FM mode selection.
• OFF : Operating mode is fixed in DV.
(default)
• ON : The transceiver automatically selects FM
mode for temporary operation.
DD
Call sign edit record
Selects the call sign programming when the call sign is edited
or corrected with the pre-programmed call sign.
• OFF : The edited or corrected call sign is over writ-
ten.
• SELECT : The edited or corrected call sign is pro-
grammed into the selected call sign memory.
• AUTO : The edited or corrected call sign is pro-
grammed into a blank channel automatically.
(default)
AUTOAUTO
SELECTSELECT
OFFOFF
EDIT RECORD
r
AUTOAUTO
SELECTSELECT
OFFOFF
EDIT RECORD
r
OFFOFF
ONON
DV AUTO DETECTDV AUTO DETECT
r
OFFOFF
ONON
DV AUTO DETECT
r
OFFOFF
5SEC5SEC
10SEC10SEC
30SEC30SEC
1MIN1MIN
GPS AUTO TXGPS AUTO TX
r
OFFOFF
5SEC5SEC
10SEC10SEC
30SEC30SEC
1MIN1MIN
GPS AUTO TX
r
