![Icom IC-91A [65/131] 2 3 4 5 6](/views2/1074080/page65/bg41.png)
59
7
DV MODE OPERATION (Optional UT-121 is required for IC-91A)
7
DD
GPS message programming
qEnter “GPS” in message/position set mode.
• GPS MESSAGE screen is displayed.
wPush [
≈≈
](6) to select the message edit condition.
• The 1st digit of the message blinks.
eRotate [DIAL]
†
to select the desired character or symbol.
• Push [A/a](3) to change the character group from “AB” (alpha-
betical characters; capital letters), “ab” (alphabetical characters;
lower case letters), “12” (numbers) and “ !”” (symbols) in se-
quence.
rPush [
≈≈
](6) to select 2nd digit, then rotate [DIAL]
†
to select
the desired character or code.
• Push [
≈≈
](6) to move the cursor right; push [
ΩΩ
](4) to move the
cursor left.
• 2nd digit blinks (1st digit stops blinking).
tRepeat the steps r and t to enter the desired message.
• Up to 20-character messages can be set.
yPush [ï](5) to store the message.
uPush [MENU/LOCK] to return to frequency indication.
DATA:DATA: AB
Hello!Hello!
†
:SET:SET
:SEL:SEL
:CUR:CUR
CLR:CLRCLR:CLR
GPS MESSAGEGPS MESSAGE
A/a:CHARA/a:CHAR
r
DATA:DATA: ABAB
†
:SET:SET
:SEL:SEL
:CUR:CUR
CLR:CLRCLR:CLR
GPS MESSAGEGPS MESSAGE
A/a:CHARA/a:CHAR
r
MENU screen ➪ MESSAGE/POSITION ➪ GPS
(Push [MENU/LOCK]) (Rotate [DIAL]
†
, then push [ï](5)
†
.)
†
[DIAL] ↔ [
∫∫
](2)/[
√√
](8) [ï](5) ↔ [
≈≈
](6)
