53
7
DV MODE OPERATION (Optional UT-121 is required for IC-91A)
7
DD
Message Transmission
Select the message transmission function ON (Ch01–05) and
OFF. When a message channel is selected, the transceiver
transmits a text message
(pre-programmed). (default: OFF)
qSet the operating frequency, call signs and other settings,
such as repeater, as desired in B band.
wPerform the steps q to e in “D TX message program-
ming” as at left.
eRotate [DIAL]
†
to select the desired message channel.
•“Ch01” to “Ch05” available.
• See left-hand pages for message programming.
rPush [ï](5) to set the message for transmission.
tPush [PTT] to transmit the selected message.
• The message is transmitted each time [PTT] is pushed.
• The message is transmitted each 30 sec. automatically during
continuous transmission.
yRelease [PTT] to return to receive.
uWhen the reply call with a message is received, the call
sign and the message scrolls at the bottom of the function
display.
✔
For your information
The automatic received call sign and/or message indication
can be turned OFF in display set mode, if desired.
➥ RX CALL SIGN
(p. 100)
➥ RX MESSAGE (p. 101)
NOTE: Only 1 message can be stored in the IC-
91A/91AD. The received message is cleared by turning
power OFF, or overwritten when another message is re-
ceived.
A transmitted message that includes lower case charac-
ters from the IC-91A/91AD may not be decoded and dis-
played correctly by the ID-800H, IC-V82/U82, etc.
DVDV
B
430 712
50
MSG:Hello!
Scrolls the received message.
†
[DIAL] ↔ [
∫∫
](2)/[
√√
](8) [ï](5) ↔ [
≈≈
](6)
