122
OPTIONS
15
• UT-121
DIGITAL UNIT
Provides DV mode operation for IC-91A. Already installed
into the IC-91AD.
• RS-91
REMOTE CONTROL SOFTWARE
Allows you to operate the transceiver, as well as the easy
memory management from the connected PC for Microsoft
®
Windows
®
98/98SE/ME/2000/XP with an RS-232C (COM)
port. In addition, low-speed data communication is enabled
with this software for DV mode operation. A data communi-
cation cable, OPC-1529R, is supplied with the software.
• BC-139
DESKTOP CHARGER
Rapidly charges BP-217 Li-ion battery pack in 2.5 hrs.
• BP-216
BATTERY CASE
Battery case for R6 (AA) × 2 alkaline batteries.
• BP-217
LI
-
ION BATTERY PACK
7.4 V/1300 mAh Lithium Ion battery pack. Battery life: 5 hrs.
(approx.; VHF, FM, high power, Tx : Rx : Standby = 1:1:8)
• HM-75A
REMOTE CONTROL MICROPHONE
Allows you to remotely select operating channels, etc.
• HM-131
SPEAKER
-
MICROPHONE
For operation while conveniently hanging the transceiver
from your belt, etc.
• HM-128/HM-153
EARPHONE
-
MICROPHONE
Ideal for hands-free operation by clipping the microphone
with the PTT switch to your lapel or breast pocket.
• HS-85
HEADSET WITH VOX
/
PTT UNIT
Hands-free headset with VOX control box.
• CP-12L
CIGARETTE LIGHTER CABLE WITH NOISE FILTER
• CP-19R
CIGARETTE LIGHTER CABLE WITH DC
-
DC CONVERTER
Allows you to operate the transceiver through a 12 V ciga-
rette lighter socket, and also charge the attached battery
pack
(during stand-by only) regularly.
CP-19R: A built-in DC-DC converter outputs 11 V DC.
• OPC-254L
DC POWER CABLE
For operation and charging via an external power supply.
• OPC-474
CLONING CABLE
Used for handheld-to-handheld cloning.
• OPC-1529R
DATA COMMUNICATION CABLE
Allows you to GPS operation in DV mode operation.
• SP-13
EARPHONE
Provides clear receive audio in noisy environments.
• LC-163
CARRYING CASE
Helps protect the transceiver from scratches, etc.
• AD-92SMA
ANTENNA CONNECTOR ADAPTER
Allows you to connect an external antenna with a BNC con-
nector.
Microsoft
®
and Windows
®
are registered trademarks of Microsoft Cor-
poration in the U.S.A. and other countries.
