102
11 MENU SCREEN OPERATION
■ Sounds set mode items
DD
Beep output level
Adjusts the key-touch beep tone level to the desired level
within 39 levels.
The key-touch beep
(following item) must be set to ON to
have a beep tone.
DD
Key-touch beep
Turns the key-touch beep ON or OFF. (default: ON)
DD
Scan stop beep
Turns the scan stop beep function ON or OFF.
(default: OFF)
DD
Scope audio output
Select the audio output function capability during sweep with
band scope function.
• ON : The received audio sounds during sweep.
(default)
• OFF : No audio sounds during sweep.
DD
Volume select
Select the volume level adjustment from Both and Separate
for dualwatch operation.
• BOTH : Both A band and B band volume level is ad-
justed with [VOL] at the same time.
(default)
• SEPARATE : The Volume setting is adjusted indepen-
dently in A and B bands with [VOL].
DD
Standby Beep
☞
Available for IC-91AD, or if the UT-121 is installed in the IC-91A.
Turns the beep emission capability ON and OFF when the com-
municating station finishes transmitting or the receive signal dis-
appears while in the digital mode operation.
(default: ON)
ONON
OFFOFF
STANDBY BEEP
r
OFFOFF
ONON
STANDBY BEEP
r
BOTHBOTH
SEPARATESEPARATE
VOLUME SELECT
r
SEPARATESEPARATE
BOTHBOTH
VOLUME SELECT
r
ONON
OFFOFF
SCOPE AF OUTPUT
r
OFFOFF
ONON
SCOPE AF OUTPUT
r
OFFOFF
ONON
SCAN STOP BEEP
r
ONON
OFFOFF
SCAN STOP BEEP
r
ONON
OFFOFF
KEY-TOUCH BEEP
r
OFFOFF
ONON
KEY-TOUCH BEEP
r
BEEP LEVELBEEP LEVEL BEEP LEVEL
Minimum level (no audio) Maximum level
