90
11 MENU SCREEN OPERATION
DD
Microphone simple mode
Microphone simple mode is used to change the function as-
signments for keys on the optional HM-75A
REMOTE CONTROL
SPEAKER
-
MICROPHONE
. (pgs. 122, 124)
• SIMPLE
• NORM-1 (default)
• NORM-2
DD
Weather alert function
Turns weather alert function ON and OFF. (p. 114)
(default: OFF)
DD
Auto power ON
Auto power ON function turns the transceiver power ON au-
tomatically after passing the set time period from power OFF.
Select the desired time period within 30 minutes to 24 hours
in 30 minutes steps and OFF.
(default: OFF)
DD
Key lock Type
While the key lock function is ON, [PWR], [PTT], [SQL],
[VOL] and [MENU](
Lock function only) can still be accessed.
Accessible keys can be set to 1 of 4 groups.
• NORMAL : [PWR], [PTT], [SQL], [VOL] and [MENU]
(Lock function only) accessible. (default)
• NO SQL : [PWR], [PTT], [SQL], and [MENU] (Lock func-
tion only) are accessible.
• NO VOL : [PWR], [PTT], [VOL], and [MENU]
(Lock func-
tion only) are accessible.
• ALL : [PWR], [PTT] and [MENU]
(Lock function only)
are accessible.
NORMALNORMAL
NO SQLNO SQL
NO VOLNO VOL
ALLALL
LOCK
r
NORMALNORMAL
NO SQLNO SQL
NO VOLNO VOL
ALLALL
LOCK
r
OFFOFF
AUTO POWER ON
24:0024:00
AUTO POWER ON
OFFOFF
ONON
WEATHER ALERT WEATHER ALERT
r
OFFOFF
ONON
WEATHER ALERT
r
U.S.A. version only
NORM-1NORM-1
SIMPLESIMPLE
NORM-2NORM-2
MIC SIMPLE MODEMIC SIMPLE MODE
r
SIMPLESIMPLE
NORM-1NORM-1
NORM-2NORM-2
MIC SIMPLE MODE
r
