107
12
OTHER FUNCTIONS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
D
Setting subaudible tones for repeater or
tone squelch
q Enter “CTCSS TONE (or RPT TONE)” in DUP/TONE… set
mode.
(pgs. 97, 98)
w Rotate [DIAL]
†
to select the desired repeater or CTCSS
tone frequency.
• Each operating band and each memory channel have indepen-
dent settings.
• See page 98 for available tone frequencies for details.
e Push [ï](5) (or [
ΩΩ
](4)) to return to DUP/TONE… set mode,
and push [MENU/LOCK] to return to frequency indication.
D Setting DTCS code for DTCS squelch or
beep
q Enter “DTCS CODE” in DUP/TONE... set mode. (p. 98)
w Rotate [DIAL]
†
to select the desired DTCS tone code.
• Each operating band and each memory channel have indepen-
dent settings.
• See page 98 for available DTCS codes for details.
e Push [ï](5) (or [
ΩΩ
](4)) to return to DUP/TONE… set mode,
and push [MENU/LOCK] to return to frequency indication.
DTCS phase mode can be selected in “DTCS POLARITY”
menu.
(p. 99)
DV SET MODE
SCAN
r
DUP/TONE...
***** MENU *****
88.5
200
500
r
300
CTCSS TONE
88.5
200
500
r
300
REPEATER TONE
DV SET MODE
SCAN
r
DUP/TONE...
***** MENU *****
023023
200200
500500
r
300300
DTCS CODE
MENU screen ➪ DUP/TONE... ➪ DTCS TONE
(Push [MENU/LOCK]) (Rotate [DIAL]
†
, then push [ï](5)
†
.)
DV SET MODE
SCAN
r
DUP/TONE...
***** MENU *****
88.588.5
200200
500500
r
300300
CTCSS TONECTCSS TONE
88.588.5
200200
500500
r
300300
REPEATER TONE
DV SET MODE
SCAN
r
DUP/TONE...
***** MENU *****
023
200
500
r
300
DTCS CODE
MENU screen ➪ DUP/TONE... ➪ CTCSS TONE
(Push [MENU/LOCK]) (Rotate [DIAL]
†
, then push [ï](5)
†
.)
†
[DIAL] ↔ [
∫∫
](2)/[
√√
](8) [ï](5) ↔ [
≈≈
](6)
