60
7 DV MODE OPERATION (Optional UT-121 is required for IC-91A)
DD
GPS message automatic transmission
qEnter “GPS AUTO TX” in DV set mode. (p. 95)
• GPS AUTO RX screen is displayed.
wRotate [DIAL]
†
to select the desired position data transmit-
ting interval from 5 sec., 10 sec., 30 sec., 1 min., 3 min.,
5 min., 10 min., 30 min. and OFF.
• The position data is transmitted only when [PTT] is pushed with
OFF setting, the data is transmitted automatically once every
5 sec., 10 sec., 30 sec., 1 min., 3 min., 5 min., 10 min. and
30 min. when the appropriate setting is selected.
• The GPS message is also transmitted if programmed.
ePush [ï](5) (or [
ΩΩ
](4)) to return to DV SET MODE screen.
rPush [MENU/LOCK] to return to frequency indication.
NOTE: Your own call sign (“MY”) should be set to activate
the GPS automatic transmission.
DD
Position indication
qEnter “POSITION” in message/position set mode.
• GPS POSITION screen is displayed.
wRotate [DIAL]
†
to select the received position data indica-
tion.
ePush [ï](5)
(or [
ΩΩ
](4)) to return to MESSAGE/POSITION
screen.
rPush [MENU/LOCK] to return to frequency indication.
MY POSITION
GPS POSITIONGPS POSITION
r
34.56.789 N34.56.789 N
123.45.678 E123.45.678 E
:RX POS:RX POS
:BACK:BACK
MENU screen ➪ MESSAGE/POSITION ➪ POSITION
(Push [MENU/LOCK]) (Rotate [DIAL]
†
, then push [ï](5)
†
.)
OFF
5SEC5SEC
10SEC10SEC
30SEC30SEC
1MIN1MIN
GPS AUTO TXGPS AUTO TX
r
MENU screen ➪ DV SET MODE ➪ GPS AUTO TX
(Push [MENU/LOCK]) (Rotate [DIAL]
†
, then push [ï](5)
†
.)
