62
7 DV MODE OPERATION (Optional UT-121 is required for IC-91A)
■ Other functions for DV mode operation
DD
DV voice memory
The IC-91A/91AD has a DV voice memory that records a total
30 second
(approx.) of received audio.
The DV voice memory is divided into 2 tracks, 15 seconds
each in a track, as the default setting.
◆ Recording received audio
qSelect DV mode in B band, and deactivate the priority
watch
(p. 83) and weather alert function (p. 114) if activated.
wWhile receiving a DV signal, push [REC].
eRotate [DIAL] to select the desired track.
•“✱” is displayed beside the track number when the selected track
has been recorded.
rPush [REC] to start recording.
• Track counter (bar meter) is displayed during record.
• The recording is paused automatically when the DV signal is in-
terrupted or when the DV audio signal cannot be received cor-
rectly. Re-starts the recording when the DV audio signal is
received correctly.
tPush [REC] again to stop recording.
• The recording stops automatically when the track becomes full.
◆ Track size setting
The track size can be changed with the following instruction.
qEnter “TRACK SIZE” in DV voice memo set mode.
• TRACK SIZE screen is displayed
wRotate [DIAL]
†
to select the desired track size.
10S/3TRACK : Makes 3 tracks and 10 seconds audio
can be recorded in each track.
15S/2TRACK : Makes 2 tracks and 15 seconds audio
can be recorded in each track.
30S/1TRACK : Makes 1 track only and 30 seconds audio
can be recorded in a track.
ePush [ï](5)
(or [
ΩΩ
](4)) to return to DV VOICE MEMO
screen.
rPush [MENU/LOCK] to return to frequency indication.
10S/3TRACK10S/3TRACK
15S/2TRACK15S/2TRACK
30S/1TRACK30S/1TRACK
TRACK SIZETRACK SIZE
r
MENU screen ➪ DV VOICE MEMO ➪ TRACK SIZE
(Push [MENU/LOCK]) (Rotate [DIAL]
†
, then push [ï](5)
†
.)
DVDV
B
440 012
50
qREC TRACK:2
