27
5
BASIC OPERATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
DD
Volume setting for dualwatch
The volume setting for dualwatch can be set for both bands
simultaneously or for each band separately in set mode.
q Enter “VOLUME SELECT” in sounds set mode. (p. 102)
w Rotate [DIAL]
†
to select “BOTH” or “SEPARATE.”
e Push [ï](5)
(or [
ΩΩ
](4)) to return to sounds set mode, and
push [MENU/LOCK] to return to frequency indication.
DD
Setting squelch level
qPush and hold [MAIN/DUAL] for 1 sec. to enter the dual-
watch operation, if necessary
wWhile pushing and holding [SQL], rotate [DIAL] to adjust
the main band’s squelch level.
•“LEVEL 1” is loose squelch and “LEVEL 9” is tight squelch.
•“AUTO” indicates automatic level adjustment with a noise pulse
count system.
•“OPEN” indicates continuously open setting.
DTCS
DTCS
W
PS
EMEM
W
PS
PRIO
PRIO
+DUP+DUP
+DUP+DUP
25
75
µ
000000
µ
000000
SQUELCH:AUTO
146 010
DTCS
DTCS
W
EMEM
W
PS
PRIO
PRIO
+DUP+DUP
+DUP+DUP
25
75
µ
000000
µ
000000
SQUELCH:LEVEL6
440 000
FMFM
440 000
PSPS
FM
146 010
DTCSDTCS
DTCSDTCS
W
PSPS
EM
W
PSPS
FM
PRIOPRIO
PRIOPRIO
+DUP
+DUP
FMFM
146 010
440 000
2525
5050
µ
000
µ
000
Setting for A band (Upper)
Setting for B band (Lower)
[DIAL]
MENU screen ➪ SOUNDS ➪ VOLUME SELECT
(Push [MENU/LOCK]) (Rotate [DIAL]
†
, then push [ï](5)
†
.)
†
[DIAL] ↔ [
∫∫
](2)/[
√√
](8) [ï](5) ↔ [
≈≈
](6)
