Icom IC-91A [102/131] I scan set mode items
![Icom IC-91A [102/131] I scan set mode items](/views2/1074080/page102/bg66.png)
96
11 MENU SCREEN OPERATION
■ Scan set mode items
DD
Priority watch
Activates priority watch or priority watch with alert (Bell).
• OFF : The priority watch is turned OFF.
(default)
• ON : The transceiver checks the memory channel fre-
quency every 5 sec.
• BELL : The transceiver checks the memory channel fre-
quency every 5 sec. You can be alerted with
beeps and blinking “S.”
DD
Scan pause timer
Selects the scan pause time. When receiving signals, the
scan pauses according to the scan pause time.
• 2–20 SEC : Scan pauses for 2–20 sec. on a received
signal in 2 sec. steps.
(default: 10 sec.)
• HOLD : Scan pauses on a received signal until it dis-
appears. Rotate [DIAL] to resume manually.
DD
Scan resume timer
Selects the scan resume time from a paused frequency after
the received signal disappears.
• 0 : Scan resumes when a received signal disap-
pears.
• 1–5 SEC : Scan pauses 1–5 sec. after a received signal
disappears.
(default: 2 sec.)
• HOLD : Scan pauses on the received signal even if it
disappears. Rotate [DIAL]
†
to resume manu-
ally.
Scan resume timer must be set shorter than scan pause
timer
(previous item), otherwise this timer does not activate.
2SEC2SEC
4SEC4SEC
3SEC3SEC
1SEC1SEC
5SEC5SEC
RESUME TIMER
r
3SEC3SEC
5SEC5SEC
4SEC4SEC
2SEC2SEC
HOLDHOLD
RESUME TIMER
r
10SEC10SEC
6SEC6SEC
8SEC8SEC
4SEC4SEC
12SEC12SEC
PAUSE TIMER
r
20SEC20SEC
16SEC16SEC
18SEC18SEC
14SEC14SEC
HOLDHOLD
PAUSE TIMER
r
OFFOFF
ONON
BELLBELL
PRIO WATCHPRIO WATCH
r
OFFOFF
ONON
BELLBELL
PRIO WATCH
r
