Icom IC-91A [91/131] Menu screen operation
![Icom IC-91A [91/131] Menu screen operation](/views2/1074080/page91/bg5b.png)
85
11
MENU SCREEN OPERATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
■ General
MENU screen is used for programming infrequently changed
values or conditions of functions.
DD
Entering MENU screen and operation
e.g.) Set “AUTO power OFF” to 30 minutes.
qPush [MENU/LOCK] to enter MENU screen.
wRotate [DIAL]
†
to select the desired menu group, then
push [ï](5)
†
.
eRotate [DIAL]
†
to select the desired item, then push
[ï](5)
†
.
rRotate [DIAL]
†
to select the desired value or condition,
then push [ï](5) to return to the setting item selection
mode.
tPush [MENU/LOCK] to return to frequency indication, re-
peat steps w to r to set another items.
[DIAL]
OFFOFF
30MIN30MIN
60MIN60MIN
90MIN90MIN
120MIN120MIN
AUTO POWER OFF
r
OFFOFF
30MIN30MIN
60MIN60MIN
90MIN90MIN
120MIN120MIN
AUTO POWER OFF
r
AP OFFAP OFF
POWER SAVEPOWER SAVE
ATTENUATORATTENUATOR
MONITORMONITOR
DIAL SPEEDDIAL SPEED
SET MODE
r
• Setting items
appear.
SET MODESET MODE
SCANSCAN
DUP/TONE...DUP/TONE...
DISPLAYDISPLAY
SOUNDSSOUNDS
***** MENU *****
r
• MENU groups
appear.
†
[DIAL] ↔ [
∫∫
](2)/[
√√
](8) [ï](5) ↔ [
≈≈
](6)
