![Icom IC-91A [61/131] 2 3 4 5 6](/views2/1074080/page61/bg3d.png)
55
7
DV MODE OPERATION (Optional UT-121 is required for IC-91A)
7
DD
Voice memory recording for automatic reply
qSelect DV mode in B band, and deactivate the priority
watch
(p. 83) and weather alert function (p. 114) if activated.
wEnter “REPLY VOICE” in DV voice memo set mode.
• REPLY VOICE screen is displayed.
eWhile pushing and holding [PTT], speak into the micro-
phone.
• Up to 10 seconds of message is recordable.
• The recording stops after 10 second or when [PTT] is released.
rPush [
ΩΩ
](4) to return to DV VOICE MEMO screen.
tPush [MENU/LOCK] to return to frequency indication.
DD
Play-back or erase the voice memory
qPush [MENU/LOCK] to select menu mode indication.
wRotate [DIAL]
†
to select “DV VOICE MEMO,” then push
[ï](5)
†
.
eRotate [DIAL]
†
to select “REPLY VOICE,” then push
[ï](5)
†
.
• REPLY VOICE screen is displayed.
rTo play-back the recorded voice memory, push [ï](5).
• Push [ï](5) again to pause, push [
≈≈
](6) to cancel the play-back.
tTo erase the recorded voice memory, push and hold
[CLR](1) for 1 sec.
REPLY VREPLY V
PTT:PTT:
●
:BACK:BACK CLR:CLRCLR:CLR
REPLY VOICEREPLY VOICE
:
r
MENU screen ➪ DV VOICE MEMO ➪ REPLY VOICE
(Push [MENU/LOCK]) (Rotate [DIAL]
†
, then push [ï](5)
†
.)
IMPORTANT!
Deactivate the dualwatch function and set minimum [VOL]
level when recording the DV voice memo.
Otherwise received audio or unwanted noise from A band is
also recorded into the voice memory.
†
[DIAL] ↔ [
∫∫
](2)/[
√√
](8) [ï](5) ↔ [
≈≈
](6)
